Parts List
(39) 1/4-20 x 1-1/2″ lg. Carriage Bolt
(38) 1/4-20 x 5/8″ lg.
Carriage Bolt
(41) #10-32 x 3/8″ lg. Truss Head
Phillips Machine Screw
(42) #10-32 x 3/4″ lg. Truss Head Phillips
Machine Screw
(43) 1/4-20 x 5/8″ lg. Truss Head Phillips
Machine Screw
(33) #10-16 x 5/8″ lg. BT
Countersunk Self-Tapping
Phillips Screw
(49) 1/4-20 x 1-1/2″ lg. Countersunk Phillips
Machine Screw
(35) #10-32 x 1″ lg. Countersunk Phillips
Machine Screw
(50) #10-24 x 3/4″ lg. Countersunk
Phillips Machine Screw
(44) #10-32 x 3/4″ lg. Countersunk
Socket Head Screw
(47) 1/8″ Hex Key (Allen Wrench)
(40) #10-32 x 1/2″ lg. Truss Head
Phillips Machine Screw
(48) M4 x 20mm lg. Countersunk Phillips
Machine Screw
