Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Random Orbit Sander
NOTE: For tool specifications refer to the nameplate on your tool.
MAXIMUM CAPACITIES
Pad diameter 5" (125 mm) or 6" (150 mm)
Abrasive diameter 5" (125 mm) or 6" (150 mm)
FIG. 1
-7-
TRIGGER SWITCH
“LOCK-ON” BUTTON
SCREW
FRONT
HANDLE
BACKING PAD
MICROFILTER
RUBBERIZED
GRIP
VARIABLE SPEED
DIAL
VENTILATION
OPENINGS
DUST
CANISTER
ABRASIVE DISC
REAR HANDLE
CORD
RUBBERIZED GRIP
VIBRATION CONTROL
SUSPENSION SYSTEM
Suspension system separates
housing and grip areas above this
point from motor housing and
sanding mechanism for low
vibration and maximum comfort
