11
RackMatic™ Adjustable Upper Rack (model dependent)
The top rack can be raised or lowered to accommodate large items in either rack. See Figure 5.
Note: Before pushing the top rack into the dishwasher, ensure the rack height is the same on both sides. If
the height is not the same on both sides, the dishwasher door will not shut and the top rack spray arm will
not connect to the water inlet.
To lower the top rack:
1 Pull the top rack out of the dishwasher until it stops.
2 Press the RackMatic adjustable top rack handles inward and let the
rack drop gently.
To raise the top rack:
1 Pull the top rack out of the dishwasher until it stops.
2 Grasp the top of the rack above the RackMatic handles and pull it
upward until the handles lock the rack into position (you do not need
to press the handles in order to raise the rack).
Figure 5
