Bosch SHV6803 - Page 114

e0
1
M
Temperature Selector Switch – b
YE-u-3a
BU-f3
VT-u-3
GN-f3
WH-u-6a
12345
On / Off Switch – a1
Door Switch – e0
WHRD-l6-9
BK-l1-L1
WHRD-A2
WH-l1-N
WHVT-u-4
RD-l6-5
21 3456
h1
a1
Timer – u
GN-I6-6
RD-A2 VT-b-3 YE-b-1 BK-m2-1 OR-I6-8 GYBK-e5-1
WHRD-A2
m1
BU-l6-4
GY-l6-1
GN-f3
WH-b-5
WH-I6-3
WHVT-a1-3
1
M
3b3a
3
4b4a4
65b5a
5
6b6a
2b2a2
GYRD-l6-8 GYRD-e6-4 BURD-m2-2 BURD-s2
L1
Drain Motor – m3
BK-a1-4 WH-a1-2 GNYE-r1
L1
N
PE-3
Electrical Supply – l1
VT-f1-2 BURD-m3
GNYE-r1
Water Solenoid – s2
RD-e5-4
GNYE-I1-PE-3 GNYE-PE-2 GNYE-s2 GNYE-m2
RD-f5
Heating Element – r1
GNYE-PE-1 GNYE-r1 GNYE-m2 GNYE-PE-4
Ground – PE
1 2
GNYE-PE-1
5
GNYE-s2
Left side panel
Right side panel
Terminal box
Control panel
Hinge
6 4
RD-u-3b WHRD-u-m1 WHRD-a1-1
Actuator (Dispenser) – A2
WHRD-a1-1
OR-u-4b
GN-u-5b
RD-a1-3
BU-u-5a
WH-u-6a
GY-u-5
BURD-m2-2 WHRD-f5 GYRD-m3-L1 GN-f4 RD-e6-1 BU-f1-1 WH-e5-2 GY-e6-2
Base Wiring Connector – l6
1 2 3 4 5 6 7 8 9
BK-u-2b BURD-m3 BURD-l6-9 GNYE-PE-1 GNYE-r1
Circulation Motor – m2
123
K1
BU-b-2
GN-u-5b
GN-b-4
Thermostat – f3
135˚F
WH-e5-2 WH-f1-4 GN-l6-6 WHRD-l6-9 RD-r1
Thermostats – f4 & f5
f4
149˚F
f5
185˚F
BU-l6-4 WH-f4 VT-s2
Water Level Switch – f1
P
4
2
1
RD-l6-5 GYRD-m3-L1 GY-l6-1
Float Switch – e6
4
2
1
RD-r1 GYBK-u-4a WH-f4 WH-l6-3
Flow Switch – e5
4 2
1
BK = black
BN = brown
RD = red
YE = yellow
GN = green
BU = blue
VT = violet
GY = gray
WH = white
OR = orange
PK = pink
High Limit
A2
GNYE-PE-6
SHU 303X/313X
HINT: Format for wire connections includes wire color and part/terminal connected to. For example, “BK-m2-1”
= BK (black wire) connected to terminal 1 of circulation motor m2.
HINT: When a wire color consists of four letters, the 3rd and 4th letters show the stripe. For example, “GYBK” wire is a gray wire with a black stripe.
Wire Color Code
