Bosch SMV6ZCX42E - Cleaning Spray Arms

en Cleaning and servicing
44
1
2
3. Pull down the micro filter to re-
move.
4. Press the locking catches to-
gether and lift the coarse filter out
⁠.
1
2
5. Clean the filter elements under run-
ning water.
Carefully clean the rim of dirt
between the coarse and the fine fil-
ter.
6. Re-assemble the filter system.
Make sure that the locking catches
on the coarse filter click into posi-
tion.
7. Insert the filter system into the ap-
pliance and turn the coarse filter
clockwise.
Make sure that the arrow markings
match up.
Cleaning spray arms
Limescale and soiling in the dish-
washing water may block the nozzles
and bearings on the spray arms.
Clean the spray arms regularly.
1. Unscrew the upper spray arm
and pull down to remove ⁠.
1
2
2. Pull up the lower spray arm to re-
move.
3. Check the outlet nozzles on the
spray arms for blockages under
running water and remove any for-
eign bodies.
