5*7&9.3,3897:(9.438
-9-
41)!9&3)
Keep fingers clear of hinge
points when folding or
unfolding the stand.
1. Unlock support leg cam lock, figure 11.
2. Rotate release lever down to clear locking
pins, figure 11.
3. With both hands on the handle, pull up and
push forward on the stand, figure 12, until
it locks in the upright position, figure 13.
#3+41)!9&3)
1. With one hand on the handle, foot on the
kick bar, pull back slightly and rotate the
release lever to disengage the locking pins.
2. With both hands on the handle, pull back,
push down, and lower the stand until it
locks in position.
3. Lock down cam lock support leg.
!
WARNING
FIG. 11
FIG. 12
FIG. 13
