24
The dishwasher drain hose may be connected to the drain plumbing using
an air gap in one of two ways:
- Connect to the under sink dishwasher drain connection (25a).
- Connect to a disposer dishwasher drain connection (25b).
NOTE: Place hose clamp around end of drain hose BEFORE connecting
to the plumbing.
The dishwasher drain hose may be connected to the drain plumbing using
a high loop in one of two ways:
- Connect to the under sink dishwasher drain connection (25c).
- Connect to a disposer dishwasher drain connection (25d).
25
a
c
b
d
C
C
C
C
