7
Overview of programmes aObserve table of consumption values on Page 8 and instructions on Page 6!
The programmes are time-control led for lightly soiled textiles. If textiles are heavily soiled, reduc e the load or select additional function, e.g. Eco
+
.
When washing at maximum load using programmes marked with *, always select Eco
+
additional function. Irrespective of the type of washing, KEasy-Care 40 °C at max. selectable spin
speed is best suited as a short programme.
Programmes without Prewash – pour detergent into dispenser II, programmes with Prewash – divide detergent between dispensers I and II.
Programmes °C max.
Type of washing
Additonal functions; information
cCottons : – 90 °C
7 kg *
Hard-wearing textiles, heat-resistant textiles made
of cotton or linen
Eco
+
, cPrewash, R educed Ironing,Aqua Plus
Cottons Eco : – 60 °C
÷Sensitive : – 60 °C
Eco
+
, cPrewash, R educed Ironing,Aqua Plus
For especially sensitive skin, extended wash cycle at selected temperature,
higher water level
5cPower Wash : – 60 °C 5 kg Hardwearing textiles made of cotton or blended fabrics Time-controlled programme, short programme for normally soiled washing
KEasy-Care
: – 60 °C
3.5 kg *
Easy-care textiles made of cotton, linen, synthetic fibres or
blended fabrics
Eco
+
, cPrewash, R educed Ironing,Aqua Plus
! Mixed Load : – 40 °C Textiles made of cotton or easy-care textiles
Eco
+
, cPrewash, R educed Ironing,Aqua Plus
Different types of washing can be washed together
cDark Wash : – 40 °C Dark textiles made of cotton and dark easy-care textiles
Eco
+
, cPrewash, R educed Ironing,Aqua Plus
Reduced rinse and final spin cycle
Delicates/Silk : – 40 °C
2 kg
For delicate, washable textiles, e.g. made of silk, satin,
synthetic fibres or blended fabrics
Eco
+
, cPrewash, R educed Ironing,Aqua Plus
No spin cycle between the rinse cycles
Z Sportswear : – 40 °C Textiles for outdoor wear
Eco
+
, cPrewash, R educed Ironing,Aqua Plus
Wool : – 40 °C Hand or machine-washable wool or rich-wool textiles
Especially gentle wash programme to prevent shrinkage, longer programme
pauses (textiles rest in wash liquor)
6Super Quick : – 40 °C
Easy-care textiles made of cotton, linen, synthetic fibres or
blended fabrics
Short programme approx. 15 minutes,
suitable for lightly soiled washing
Additional
programmes
2 Rinse, Spin, <Drain, Gentle S pin
9205 / 9000762955
*762955*
WIS28440GB
Robert Bosch Hausgeräte G mbH
Carl-Wery-Str. 34
81739 München/Deutsc hland
8
Safety instructions
– Read and follow the operating and installation ins tructions and all other information enclosed with the washing
machine.
– Retain documents for subsequent use.
Risk of electric shock – Never pull out the mains plug by tugging the power cord!
– Insert/pull out the mains plug with dry hands only.
Danger to life On redundant appliances:
– Pull out the mains plug!
– Sever the power cord and discard together with the plug.
– Destroy the lock on the washing-machine door. Th is will prevent children from
locking themselves in and suffocating.
Risk of suffocation – Keep packagi ng, plastic film and packaging parts out of the reach of children.
Risk of poisioning – Keep detergents and care products out o f the reach of children.
Risk of explosion – Caused by detergents co ntaining solvents, e.g. stain remover/items of washing
pretreated with solvent naphtha may result i n an explosion after being loaded into
the washing machine.
Before hand thoroughly rinse items of wa shing by hand.
Risk of injury – Washing machine door may beco me very hot.
– Caution when draining hot detergent solution .
– Do not climb on the washing machine.
– Do not lean on the open washing machine door .
– Do not reach into the drum in case it is still rotati ng.
Consumption values
Programme
Additonal
function
Load Current** Water**
Programme
duration
**
cCottons 30 °C*
Eco
+
7 kg 0.55 kWh 75 l 2 :12 h
cCottons 40 °C*
Eco
+
7 kg 0.85 kWh 75 l 2 :12 h
cCottons 60 °C*
Eco
+
7 kg 1.50 kWh 75 l 2 :12 h
cCottons 90 °C
Eco
+
7 kg 2.51 kWh 90 l 2 :12 h
KEasy-Care 40 °C*
Eco
+
3.5 kg 0.55 kWh 55 l 1:12 h
Delicates/Silk 30 °C - 2 kg 0.20 kWh 39 l 0:40 h
Wool 30 °C - 2 kg 0.20 kWh 40 l 0:36 h
* Programme setting for test according to currently valid European standard 60456.
Information about comparability tests:
To test the test programmes, wash indicated load, with Eco
+
additional function and at maximum selectable s pin speed.
Programme
Additonal
function
Load
Annual energy
consumption
Annual water
consumption
Cottons Eco
Eco
+
**
7/3.5 kg 218 kWh 10560 l
** Programme setting for testing and energy labelling ac cording to directive 2010/30/EU with cold water (15 °C).
***The values may dev iate from the stated values depending on water pressure and hardness, room temp erature, type and
amount of laundry, detergents used, fluctuation s in the mains voltage and selected additional functions.
9
Insert for liquid detergent depending on model
Position insert for dosing liquid det ergent:
– Completely remove detergent drawer .
a
Page 10
– Push insert forwards.
Do not use insert (push upwards):
– For gel-like detergents and washing powders,
– For programmes with cPr ewash or (Ready in) optio n.
Care
ʑ
Machine housing, control panel
– Remove detergent residue immediately.
– Wipe with a soft, damp cloth.
– Do not clean the appliance with a water jet.
Clean the detergent drawer ...
... if it contains detergent or fabric s oftener residue.
1. Pull out, depress insert, take out drawer all the way.
2. Take out insert: using your finger, press insert upwards.
3. Clean detergent dispenser and insert with water and a brush and dry .
4. Attach insert and lock into position (push cylinder onto guide pin).
5. Slide in the detergent dispenser.
Leave detergent drawer open so that res idual water can evaporate.
ʑ
Drum
Leave washing machine door open so th at the drum can dry out.
Use chlorine-free cleaning agent, not s teel wool.
ʑ
Descaling No washing in the mach ine!
Not required if detergent dosed correctly. H owever, if this does occur, follow the instructions of the descaling agent
manufacturer. Suitable descalers ca n be purchased on our website or from customer s ervice.
Information on the display panel depending on mode l
¨:³±Clo se the washing machine door properly; washing may be caught.
¨:³Å, ÉTurn on tap fully, supply hose kinked/jammed; clean filter aPage 10, water press ure too low.
¨:³µDr ain pump blocked; clean drain pump. aPage 10
Drainage hose/outlet pipe blocked; clean dr ainage hose on the siphon. aPage 10
¨: ´Water in the base pan, appliance leaking. Ca ll customer service!
¨: , ´, Motor fault. Call customer ser vice. aInstallation Instructi ons
Other displays Switch off appliance, wait 5 seco nds and switch on again. If the display is indicated again,
call customer service. aInstallation Instructions
– Risk of electric shock! Pull out the mains plug!
– Risk of explosion! No solvents!
10
Maintenance
Detergent-solu tion pump
Set programme selector to Off , pull o ut the mains plug.
1. Take the drainage hose out of the holder.
Remove sealing cap, allow detergent solutio n to flow out.
Put the closing cap back on the hose.
2. Carefully unscrew the pump cover (residual water).
3. Clean the interior, pump cover thread and pump housing
(fan impeller in the detergent-solution p ump must rotate).
4. Reinsert and screw on pump cover. Handle is upright. Insert the drai n hose into the holder.
To prevent unused detergent from flowing in to the outlet during the next wash:
Pour 1 litre of water into dispenser II and start the <Dr ain programme.
Drainage hose on the siphon
Set programme selector to Off, pull ou t the mains plug.
1. Loosen hose clip, carefully remove drainage hose (residual water).
2. Clean drainage hose and siphon spigot.
3. Re-attach drainage hose and secure connection point with hose cl ip.
Filter in the water inlet hose
Risk of electric shock!
Do not immerse Aqua-Stop safety device in water (contains electric valve).
Release water pressure in the supply hose:
1. Turn off the tap!
2. Select any programme (except Spi n/<Drain).
3. Select Start/Pause. Leave programme for ap prox. 40 seconds.
4. Turn the programme selector to
Off. Pull out the mains plug.
Clean the filter:
5. Disconnect the hose from the water tap.
Clean filter with small brush.
and/or for standard and Aqua-Secure models:
remove hose from the rear of the appliance,
take out filter with pliers and clean.
6. Connect the hose and check for leaks.
Risk of scalding!
– A llow detergent solution to cool down!
– Tu rn off the tap!
11
What to do if …
ʑ
Water is running out . – Correctly attach/replace drainage h ose.
– Tighten screw-fitting on the supply hose.
ʑ
Water not flowing in.
Detergent not washed i n.
– Start/Pause not selected?
– Tap not open?
– Filter blocked? Clean the filte r. aPage 10
– Supply hose kinked or jammed ?
ʑ
Washing-machine door cannot
be opened.
– Safety function a ctive. Stop programme? aPage 4
– (rinse stop = without final spin) selected? aPage 3, 4
– Can be open ed via emergency release only? aPage 6
ʑ
Programme does not st art. – St art/Pause or (Ready in) time selected?
– Door closed?
ʑ
Detergent solution is not drained. – (rinse stop = without final s pin) selected? aPage 3, 4
– Clean the drain pump. aPage 10
– Clean outlet pipe and/or drai nage hose.
ʑ
Water not visible in the drum. – No t a fault – water below the visible area.
ʑ
Spin result not satisfacto ry,
washing wet/too damp.
– Not a fault – unbalanced load d etection system has stopped the spin cycle,
washing unevenly distributed.
Distribute small and large items of washing in the drum.
–
Reduced Ironing selected? aPage 5
– Too low spee d selected? aP age 5
ʑ
The programme durati on
changes during the wa sh cycle.
– Not a fault – the programme sequence is optimised for the particular wash process.
This may result in changes to the programme duration in the display field.
ʑ
Spin cycle actuated seve ral
times.
– Not a fault – unbalanced load d etection system adjusts imbalance.
ʑ
Residual water in the di spenser
for care product ~.
– Not a fault – effect of the care product not impaired.
– If required, c lean insert. aP age 9
ʑ
Odour formation in the wash ing
machine.
– Run Cottons 90 °C programme without washing. Use standard detergent.
ʑ
Foam is coming out of the
detergent drawer.
– Too much dete rgent used?
Mix 1 tablespoon of fabric softener with ½ litre of water and pour into disp enser II
(not for outdoor, sports and down-filled textiles!).
– Reduce detergent dosage for th e next wash cycle.
ʑ
Loud noise formation, vibr ations
and “Wandering” duri ng spin
cycle.
– Appliance feet f ixed? Secure appliance feet. aInstallation Inst ructions
– Transportation p rotection devices removed?
Remove transportation pro tection devices. aInstallation Instructions
ʑ
Noises during spin and drain
cycles.
– Clean the drain pump. aPage 10
ʑ
Display panel/indicator lig hts do
not function while the a ppliance
is running.
– Power failure?
– Fuse tripped? Switch on/replace fuse.
– If the fault occurs repeatedly, call customer service.
ʑ
The programme takes l onger
than usual.
– Not a fault – unbalanced load d etection system adjusts imbalance by repeate dly
distributing the washing.
– Not a fault – foam detection sy stem active – a rinse cycle is switched on.
ʑ
Detergent residue on the
washing.
– Occasionally phosphate-free detergents contain water-insoluble residue.
– Select
2 Rinse or brush the l aundry after washing.
ʑ
In the pause status Start/
Pause flashes very quickly and a
signal sounds.
– Water level too high. Washing cannot be reloaded.
Immediately close washing machine door.
– Select St art/Pause to continue the programme.
If a fault cannot be recti fied (switching the machine on and off) or a re pair is required:
– Set programm e selector to Off and pull out the mains plug.
– Turn off the ta p and call customer service. aInstallation Instr uctions
Washing machine
en Operating instructions
To Next Page
Loading...
