Programme overview also see Page 5
After drying: laundry is to be ...
T-shirt
Shirts
Trousers
Skirts/dresses
Sportswear
Work clothing
Anoraks
Terry/
bathrobe
Underwear
Socks
Bed linen
Table linen
Terry towels
Tea towels/
towels
c
ironed
lightly ironed dry
@c
not ironed
c
passed through a mangle
Resistentes/Algod.
(Cottons)
max. 7 kg For whites and coloureds/cotton or linen.
Seco c(Iron Dry) cø@c
è**è*è*è*è*è*è*
Seco para guardar
(Cupboard Dry)
ccccccccc@
è*è*è*è*è*
Extra seco (Very Dry) ccccccccc@
*è*è*è*è*è*
Sintéticos (Easy-Care)
max. 3.5 kg For non-iron laundry made of synthetic fibres and blended fabric, cotton.
Seco c(Iron Dry) cø@c
è*è*è*è*è*è*
Seco para guardar
(Cupboard Dry)
ccccccccc@
è*è*
*
Timed Programmes
max. 3.5 kg For pre-dried , quilted, delicate fabrics made of acrylic, or separate small items of laundry.
60 min caliente/quente (warm)
For quilted, delicate fabrics made of acrylic an d cotton.
40 min caliente/quente (warm)
20 min caliente/quente (warm)
For pre-dried, quilted, delicate fabrics made of acry lic and cotton, or separate small items of laundry.
Also for subsequent drying.
20 min frio (cold)
For all types of fabrics. For freshening up or airing items of laundry that have been worn for a short period of time.
1110 / 9000505317
*505317*
Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München, Deutschland
WTC84101EE
8
Installation
– Delivery specification : dryer, instructions for installation and use.
– Check dryer for transport damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not lift the dryer b y protruding parts (e.g. the door) - risk o f breakage.
– Do not set up in a room that is susceptible to frost.
Freezing water may cause damage.
– If in doubt, have the ap pliance connected by an expert.
Setting up the dryer
– The appliance plug must always be accessible.
– Ensure that the appliance is installed on a clean, level
and firm surface.
– Keep the air inlet on the front of the dryer clear.
– Keep the area around the dryer clean.
– Adjust the height of t he dryer using the threaded
feet at the front.
Do not remove the threaded feet unde r any
circumstances.
Mains connection safety information a page 11 .
– Connect to an AC earth ed socket. If in doubt have the socket ch ecked by an expert.
– The mains voltage and the voltage shown on the rating plate (
aPage 9) must correspond.
– The connected load and necessary fuse protection are speci fied on the rating plate.
Changing the power input Ensure that the socket is fu sed.
Frost protection / Transport
Preparation
Empty the condensation container
apage 4.
The dryer contains residual water;
this can flow out if the dryer is ti lted.
Take all accessory parts out
of the drum. The drum must
be empty.
Make sure that the air inlet
remains unobstructed
Clean and level
Set to Stop
(Off).
Press and hold the Delicado
(Low heat) button and turn the
programme selector once to.
Set to Stop
(Off).
To change the power
input, press the Fácil
(Easy-iron) button.
Do not operate the dryer if there
is a danger of frost.
Do not install the dryer behind a door or s liding
door, as these may prevent the dryer do or from
opening.
Observing this instruction may stop a ch ild from
becoming shut inside the dryer and havi ng its life
put in danger.
9
Technical data
Dimensions (DxWxH) 60 x 60 x 85 cm
Weight approximately 35 kg
Max. capacity 7 kg
Condensation container approx. 4.2 l
Ambient temperature 5 - 35 °C
Connection voltage 220 - 240 V
Connected load 2025 / 2600 W
Fuse protection 10 / 16 A
Product number
a Rating plate or inside of the door
Production number
You can find the rating plate on the back of the dryer.
ʠ
Consumption rates
These are guide values determined under standard
conditions. Deviations of up to 10 % are possible. The value
on the label is achieved at the maximu m heat setting.
Spin speed in rpm
(residual moisture)
Drying time** in
minutes, includ-
ing 8 minutes
cool cycle
Energy
consumption**
in kWh
Resistentes/Algod.
(Cottons) 7 kg
10 A 16 A 10 A 16 A
Seco para guardar
(Cupboard Dry)*
1400 (aprox. 50%) 98 90 3.32 3.32
1000 (aprox. 60%) 117 106 3.92 3.92
800 (aprox. 70%) 1 38 120 4.48 4.48
1400 (aprox. 50%) 76 66 2.45 2.45
Seco (Iron Dry) * 1000 (aprox. 60%) 91 82 2.94 2.94
800 (aprox. 70%) 106 96 3.43 3.43
Sintéticos (Easy-Care)c3.5 kg
800 (aprox. 40%) 42 40 1.16 1 .16
Seco para guardar
(Cupboard Dry)*
600 (aprox. 50%) 53 45 1.45 1 .45
*Test program to DIN EN 61121.
**The values may deviate from the va lues shown here, because of over/undervo ltage, type
of fabric, composition of the laundry to be dried, residual moisture in the material and size of
the load.
Optional accessories (order from the a fter-sales service using the order number)
Washer-dryer stack connection set
The dryer can be placed on top of a suitable washing machine with the same width and depth
to save space. This connection set must always be used to secure the dryer to the washi ng
machine. If the worktop of the was hing machine is less than 544 mm deep, please consult
the after-sales service or your spec ialist retailer.
Platform
For easier loading and unloading. The basket in the pull-out can be used for ca rrying the
laundry.
Installation underneath the worktop
Risk of electric shock.
Instead of the appliance covering pla te, you must have a metal cover fitted by an expert.
10
What to do if ...
If you cannot rectify a fault yourse lf, please contact our after-sal es service. We will always find
an appropriate solutio n and will avoid unnec essary visits by engineer s. Trust the expertise o f
the manufacturer an d rest assured that the repair will be carried ou t by trained service
technicians using original spare part s. The contact details of your local after-sales servic e can
be found in the enclo sed
after-sales service directory, or by calling one of thes e numbers:
– GB 0844 8928979 (Calla from a BT landline will be charged at up to 3 pence per minute.
A call set-up fee of up to 6 pence may apply.)
– IE 01450 2655
When contacting the after- sales service, please quote the appliance's product numb er (E no.)
and production num ber (FD) (see the inside of the door).
Set the programme se lector to
Stop (Off) and remove the applia nce plug from the sock et.
ʠ
The Inicio/Stop (Start/Stop)
indicator light does not come on.
Mains plug plugged in?
Programme selected?
Check the socket fuse.
ʠ
The Depósito/Limp. o/p
(Container/Clean) indicator light
comes on.
Empty the condensation container
apage 4.
ʠ
The Depósito/Limp. o/p
(Container/Clean) indicator light is
flashing.
Clean the fluff filter
apage 4.
Clean the air cooler if necessary
a page 6.
ʠ
Dryer does not start. Has the Inicio/Stop (Start/Stop) butt on been pressed?
Door closed?
Programme set?
ʠ
Programme stops shortly after it
has started.
Ambient temperature greater than 5 °C?
ʠ
Water is leaking out. Make sure the dryer is level.
ʠ
The door opens by itself. Push the door closed until you hear it engage.
ʠ
The required degree of dryness
was not achieved or the drying
time was too long.
Clean the fluff filter
apage 4.
Empty the condensation container.
Ambient temperature higher than 35 °C a airing.
Air inlet may be blocked
a keep unobstructed.
Was an unsuitable programme sele cted?
apage 7.
Has the dryer been installed with suffici ent space on all
sides? Ensure that air can circulate .
Mains failure a Restart the dryer.
Thin layer of limescale on the moisture sensors. Clean the
moisture sensors
apage 6.
ʠ
Laundry damp. Use the next drying programme up or use the timer
programme as a supplement
apage 7.
Warm laundry feels damper than it really is!
ʠ
The humidity in the room
has increased significantly.
Make sure the room is sufficiently venti lated.
Air inlet blocked?
a keep unobstructed.
Ensure that the air cooler is in use .
ʠ
One or more indicator lights is/are
flashing.
Clean the air fluff filter and air cooler if n ecessary
apage 4/6.
Check the installation conditions apage 8.
Switch off, allow to cool, switch on again and restart the
programme.
ʠ
Mains failure. Remove laundry from the dryer imme diately and spread
out. This allows the heat to dissipate .
11
Safety instructions
Emergency
– Pull the appliance plug out of the socket immediately or disconnect th e fuse.
ONLY use the
dryer...
– In rooms inside the house.
– To dry fabrics.
The dryer must
NEVER...
– Be used for other purposes than those described above.
– Be modified in terms of its technology or attributes.
Dangers
– The dryer must not be used by children or persons who have not be en
instructed in its use.
– Do not leave children unsupe rvised near the dryer.
– Keep pets away from the dry er.
– Remove all objects from pockets.
Make especially sure that cigarette lighters are removed as they constitute an
a explosion hazard.
– Do not lean or sit on the do or
a risk of tipping.
– Open the door carefully. Hot ste am may escape.
Installation
– Secure loose cables a tripping hazard.
– Do not operate the dryer i f there is a risk of frost.
Mains
connection
– Connect the dryer accordi ng to specifications to an AC earthed socket, as
otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-section mu st be sufficient.
– Only use earth-leakage cir cuit breakers with the following symbol:
– The appliance plug and so cket must be compatible.
– Do not use multiple plugs/c ouplings and/or extension cables.
– Do not touch or hold the app liance plug with wet hands
a risk of electric shock.
– Never pull the appliance pl ug out of the socket by its cable.
– Do not damage the mains l ead a risk of electric shock.
Operation
– Only load the drum with laun dry.
Check the contents before you switc h the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair setting spray, nai l polish remover, stain remover,
cleaning solvent, etc.)
a fire/explosion hazard.
– Dust (e.g. coal dust, flour) poses a danger:
do not use the dryer
a explosion hazard.
– Do not put laundry containing foamed material/rubber in the dryer
a elastic
material may be destroyed and the d ryer may be damaged due to possibl e
deformation of the foamed material.
– Switch off the dryer once the programme has ended.
– Condensation is not drinking water and may be contaminated with f luff.
Defect
– Do not use the dryer if it is def ective or if you suspect it is.
Repairs must only be carried out by t he after-sales service.
– Do not use the dryer if the m ains cable is defective. To avoid dang er, only
have the defective mains cable replac ed by the after-sales service.
Spare parts
– Only use genuine spare parts and accessories for safety reasons.
Disposal
– Dryer: pull out the appliance plug, then cut off the mains cable from the
appliance. Dispose of the appliance at a municipal waste disposal facility.
– Packaging: do not leave chi ldren alone with packing parts
a risk of suffocation.
– All materials are environmen tally safe and can be reused. Dispose of all
materials in an environmentally-respons ible manner.
Instructions for installation and use
Tumble dryer
en
Read these instructions before opera ting the dryer.
Observe the safety instructions on pa ge 11.
