Programme overview also see Page 5
Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying.
After drying...
c
iron laundry
lightly iron laundry
@c
do not iron laundry
c
mangle laundry
PROGRAMMES TEXTILE TYPE AND INFORMATION
**Algodón/Algodão
(Cottons)
max. 7 kg
Hard-wearing fabrics, boil-resistant fabrics made of cotton or linen.
**Sintéticos (Synthetics)
max. 3.5 kg Non-iron laundry made of synthetic fibres and blended fabric, easy-care cotton.
Seco
c(Iron Dry) c÷@c Fabrics suitable for ironing (iron fabrics in order to avoid creasing).
Seco para guardar (Cupboard Dry)
@Single-layer fabrics.
*Extra seco (Very Dry)
@Fabrics made of thick, multilayered items of clothing.
60 min caliente/quente
(60min warm)
max. 3 kg
Pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small items of laundry. Also for subsequent
drying.
40 min caliente/quente
(40min warm)
20 min caliente/quente
(20min warm)
20 min frio (20min cold) max. 3 kg
All types of fabrics. For freshening up or airing of items of laundry that have been worn for a short period of time.
*only for the Cottons programme.
**Dryness levels can be selected individually a
Extra seco (Very Dry), Seco para guardar (Cupboard Dry) and Seco c(Iron Dry) (depending on the model).
Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing. Recommendation: Dry separately.
9306 / 9000851794
*851794*
Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München/Deutschland
WTC84102EE
8
Installation
– Delivery specification: dryer, instructions for installation and use.
– Check dryer for transport damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not lift the dryer by protruding parts (e.g. the door) - risk of breakage.
– Do not set up in a room that is susceptible to frost.
Freezing water may cause damage.
– If in doubt, have the appliance connected by an expert.
Setting up the dryer
– The appliance plug must always be accessible.
– Ensure that the appliance is installed on a clean, level
and firm surface.
– Keep the air inlet on the front of the dryer clear.
– Keep the area around the dryer clean.
– Adjust the height of the dryer using the threaded
feet at the front.
Do not remove the threaded feet under any
circumstances.
Mains connection safety information a page 11.
– Connect to an AC earthed socket. If in doubt have the socket checked by an expert.
– The mains voltage and the voltage shown on the rating plate (
aPage 9) must correspond.
– The connected load and necessary fuse protection are specified on the rating plate.
Changing the power input Ensure that the socket is fused.
Frost protection / Transport
Preparation
Empty the condensation container
apage 4.
The dryer contains residual water;
this can flow out if the dryer is tilted.
Take all accessory parts out
of the drum. The drum must
be empty.
Set to Stop
(Off).
Press and hold the Delicado
(Low heat) button and turn the
programme selector once to.
Set to Stop
(Off).
To change the power
input, press the Fácil
S
(Easy-iron) button.
Do not operate the dryer if there
is a danger of frost.
Do not install the dryer behind a door or sliding
door, as these may prevent the dryer door from
opening.
Observing this instruction may stop a child from
becoming shut inside the dryer and having its life
put in danger.
Make sure that the air inlet
remains unobstructed
Clean and level
9
Technical data
ʠ
Dimensions (DxWxH) 60 x 60 x 85 cm
Weight approximately 35 kg
Max. capacity 7 kg
Condensation container approx. 4.2 l
Ambient temperature 5 - 35 °C
Connection voltage 220 - 240 V
Connected load 2025 / 2600 W
Fuse protection 10 A / 16 A
Product number
a
Rating plate or inside of the door
Production number
You can find the rating plate on the back of the dryer.
Consumption rates (The value on the label is achieved at the maximum heat setting.)
Fabrics/programmes
Residual moisture in the
fabrics after spinning
Drying time** Energy
consumption**
Algodón/Algodão
(Cottons) 7 kg
10 A 16 A 10 A 16 A
Seco para guardar
(Cupboard Dry)*
1400 rpm (50%) 121 min 104 min 3.73 kWh 3.73 kWh
1000 rpm (60%) 144 min 123 min 4.40 kWh 4.40 kWh
800 rpm (70%) 170 min 139 min 5.03 kWh 5.03 kWh
Seco (Iron Dry)* 1400 rpm (50%) 94 min 77 min 2.75 kWh 2.75 kWh
1000 rpm (60%) 112 min 95 min 3.30 kWh 3.30 kWh
800 rpm (70%) 130 min 111 min 3.85 kWh 3.85 kWh
Sintéticos (Synthetics)c3.5 kg
seco para guardar
(Cupboard Dry)*
800 rpm (40%) 42 min 40 min 1.16 kWh 1.16 kWh
600 rpm (50%) 53 min 45 min 1.45 kWh 1.45 kWh
* Programme setting for testing in accordance with applicable standard EN61121.
** The values may differ from those specified, depending on the type of fabric, composition of
laundry to be dried, residual moisture in the fabric and the amount of laundry being loaded.
Fabrics/programmes Drying time Annual energy consumption
Algodón/Algodão
(Cottons) 7 kg / 3.5 kg*
Seco para guardar
(Cupboard Dry)***
94 min / per cycle 527 kWh / per year
***Programme setting for testing and energy labelling in accordance with Directive 2010/30/EU.
Optional accessories (from after-sales service using order number)
Washer-dryer stack connection set
The dryer can be placed on top of a suitable washing machine with the same width and depth
to save space. The dryer must be fastened on the washing machine with this connection set.
If the worktop of the washing machine is less than 544 mm deep, please consult the
after-sales service or your specialist retailer.
Platform
For easier loading and unloading. The basket contained in the drawer can be used to carry
the laundry.
10
What to do if ...
If you cannot rectify a fault yourself (e.g. switching off/on), please contact our after-sales
service. We will always find an appropriate solution and will avoid unnecessary visits by
engineers. Trust the expertise of the manufacturer and rest assured that the repair will be
carried out by trained service technicians using original spare parts. The contact details of your
local after-sales service can be found in the enclosed
after-sales service directory, or by
calling one of these numbers:
– GB 0844 8928979 (Calls from a BT landline will be charged at up to 3 pence per minute.
A call set-up fee of up to 6 pence may apply.)
– IE 01450 2655
(0.03 € per minute at peak. Off peak 0.0088 € per minute.)
When contacting the after-sales service, please quote the appliance's product number (E no.)
and production number (FD) (see the inside of the door).
Set the programme selector to
Stop (Off) and remove the appliance plug from the socket.
ʠ
The Inicio/Stop (Start/Stop)
indicator light does not come on.
Mains plug plugged in?
Programme selected? Check the socket fuse.
ʠ
The display panel light and
indicator lights (depending on
model) go out and the Inicio/Stop
(Start/Stop) indicator light flashes.
Energy-saving mode is activated
a
see the separate Energy-saving mode instructions.
ʠ
The Vaciado de depósito/Limp.
./Ä (Container/Clean) indicator
light comes on.
Empty the condensation container
apage 4.
ʠ
The Vaciado de depósito/Limp.
./Ä (Container/Clean) indicator
light is flashing.
Clean the fluff filter
apage 4.
Clean the air cooler if necessary
a page 6.
ʠ
Dryer does not start. Has the Inicio/Stop (Start/Stop) button been pressed?
Door closed? Programme set?
ʠ
Programme stops shortly after it
has started.
Ambient temperature greater than 5 °C?
ʠ
Water is leaking out. Make sure the dryer is level.
ʠ
The door opens by itself. Push the door closed until you hear it engage.
ʠ
The required degree of dryness
was not achieved or the drying
time was too long.
Clean the fluff filter
apage 4.
Empty the condensation container.
Ambient temperature higher than 35 °C
a airing.
Air inlet may be blocked
a keep unobstructed.
Was an unsuitable programme selected?
apage 7.
Has the dryer been installed with sufficient space on all
sides? Ensure that air can circulate.
Mains failure
a Restart the dryer.
Thin layer of limescale on the moisture sensors. Clean the
moisture sensors
apage 6.
ʠ
Laundry damp. Use the next drying programme up or use the timer
programme as a supplement
apage 7.
Warm laundry feels damper than it really is!
ʠ
The humidity in the room
has increased significantly.
Make sure the room is sufficiently ventilated.
Air inlet blocked?
a keep unobstructed.
Ensure that the air cooler is in use.
ʠ
One or more indicator lights is/are
flashing.
Clean the air fluff filter and air cooler if necessary
apage 4/6.
Check the installation conditions apage 8.
Switch off, allow to cool, switch on again and restart the
programme.
ʠ
Mains failure. Remove laundry from the dryer immediately
and spread out. This allows the heat to dissipate.
11
Safety instructions
Emergency
– Pull the appliance plug out of the socket immediately or disconnect the fuse.
ONLY use the
dryer...
– in rooms inside the house.
– to dry fabrics.
The dryer must
NEVER...
– be used for other purposes than those described above.
– be modified in terms of its technology or attributes.
Dangers
– The dryer must not be used by children or persons who have not been
instructed in its use.
– Do not leave children unsupervised near the dryer.
– Keep pets away from the dryer.
– Remove all objects from pockets.
Make especially sure that cigarette lighters are removed as they constitute an
a explosion hazard.
– Do not lean or sit on the door
a risk of tipping.
– Open the door carefully. Hot steam may escape.
Installation
– Secure loose cables a tripping hazard.
– Do not operate the dryer if there is a risk of frost.
Mains
connection
– Connect the dryer according to specifications to an AC earthed socket, as
otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-section must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug and socket must be compatible.
– Do not use multiple plugs/couplings and/or extension cables.
– Do not touch or hold the appliance plug with wet hands
a risk of electric shock.
– Never pull the appliance plug out of the socket by its cable.
– Do not damage the mains lead
a risk of electric shock.
Operation
– Only load the drum with laundry.
Check the contents before you switch the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair setting spray, nail polish remover, stain remover,
cleaning solvent, etc.)
a fire/explosion hazard.
– Dust (e.g. coal dust, flour) poses a danger:
do not use the dryer
a explosion hazard.
– Do not put laundry containing foamed material/rubber in the dryer
a elastic
material may be destroyed and the dryer may be damaged due to possible
deformation of the foamed material.
– Switch off the dryer once the programme has ended.
– Condensation is not drinking water and may be contaminated with fluff.
Defect
– Do not use the dryer if it is defective or if you suspect it is.
Repairs must only be carried out by the after-sales service.
– Do not use the dryer if the mains cable is defective. To avoid danger, only
have the defective mains cable replaced by the after-sales service.
Spare parts
– Only use genuine spare parts and accessories for safety reasons.
Disposal
– Dryer: pull out the appliance plug, then cut off the mains cable from the
appliance. Dispose of the appliance at a municipal waste disposal facility.
– Packaging: do not leave children alone with packing parts
a risk of suffocation.
– All materials are environmentally safe and can be reused. Dispose of all
materials in an environmentally-responsible manner.
Dryer
en Instruction manual
To Next Page
Loading...
