ELECTRICAL PART LIST
1401 Series I
Resistors (continued)
Reference Designator Description Part Number Note
R95 330K, 5%, CF 113774-334
R158 12K, 2%, CF 113773-123 3
R201, 208 47K, 5%, CF 113774-473 3
R202 220K, 5%, CF 113774-224 3
R203, 209 22K, 5%, CF 113774-223 3
R205 1 Ohm, 5%, CF 113774-103 3
R206 2 Ohm, 5%, CF 113774-2RO 3
R207 100K, 5%, CF 113774-104 3
R210 510 Ohm, 5%, CF 113774-511 3
Capacitors
Reference Designator Description Part Number Note
C1, 61, 63, 69, 72, 77, 79 .01uF, 25V, 20%, Cer Disc 102399
C2 330uF, 16V, Electrolytic 113173
C3, 52, 61, 64, 65, 85, 201 10uF, 25V ,Electrolytic 106777 3
C4 4700uF, 18V, Electrolytic 112555
C11, 21, 31, 41 680pF ,100V ,10%, Cer
Disc
106541-681
C12, 42 43pF, 200V, 10%, Cer Disc 104413-430
C13, 15, 23, 25, 33, 35, 43,
45
1800pF, 100V, 10%, Cer
Disc
106542-182
C14, 24, 34, 44 1000uF, 16V, Electrolytic 112554
C22, 32 27pF, 200V, 10%, Cer Disc 104413-270
C51, 58, 79 0.12uF, 50V, 5%, Film 114036
C52, 60 .0056uF, 50V, 5%, Film 106537-561
C54, 55, 62, 70, 71, 73-75,
76, 81, 82, 83, 152
1uF, 25V, Electrolytic 104015 3
C53, 202 10uF, 25V, Tantalum 114035 3
C51, 64, 84, 203 .0056uF, 50V, 5%, Film 114037
C56, 60, 66, 68, 69, 73, 74,
76, 80
.01uF, 50V, 5%, Film 112774 3
C55, 57, 62, 65, 66, 67, 72,
78, 86, 150
.022uF, 50V, 5%, Film 112772 3
C53, 59, 81 560pF, 100V, 5%, Film 106537-561 3
C67, 151 75pF, 50V, 10%, Cer Disc 114412-750 3
C68, 153 1500pF, 50V, 10%, Cer
Disc
106542-152 3
C57, 70 .047uF, 50V, 5%, Film 112797 3
Diodes
Reference Designator Description Part Number Note
D2 IN5355B (Zener 18V/5W)
IN5355B (Zener 18V/5W)
122893
120559 ALT.
D11-13, 21-23, 31-33, 41-
43, 50, 52, 201
IN4148 114048
D51, 202 IN5240B (Zener) 114058
Zl, 50 CLM-6000 (Opto Isolator) 112540
