4
SPECIFICATIONS
Power
O
utput:
1401 four channels
1201 two channels
100 Watts continuous into 0.45 Ohms
50 Watts continuous into 0.45 Ohms
Individual Amplifiers: 25 Watts continuous into 0.45 Ohms
resistive loads from 40 Hz to 17 kHz with
less than .09% THD with 14.4 Volts DC
IM Distortion: 0.4% at 20 Watts output
Frequency Response: ± 1 dB from nominal equalization curve 40
Hz to 16 kHz with the bass control
centered and the spatial control centered
Separation: Not less than 40 dB above 500 Hz, spatial
slide control centered
Signal to Noise Ratio: Greater than 70 dB, "A" Weighted
Sensitivity:
Low Level Input:
High Level Input:
(1201 Input Level Adjustable)
250 mVrms for 25 Watts output at 1 kHz
2.75 Vrms for 25 Watts output at 1 kHz
Power On/Off:
1401 series I
1401 series II and 1201
Slide switch, controls power to booster and
accessory power output line
Remote Turn-On Capability
Power Indicator:
(1401 I and II only)
Green LED
Low Frequency Control:
(1401 I and II only)
Slider, ± 8 dB relative to nominal position in
two octave band, centered at
approximately 170 Hz (refer to the
response graphs)
Spatial Control™:
(1401 I and II only)
Slider, providing front to back speaker
balance adjustment above 200 Hz
Rear Panel Treble Switch:
(1401 I and II only)
Two position switch, 6 dB/octave relative
attenuation on rear channels, beginning at
5 kHz
Rear Panel Switches and Controls:
(1201 only)
1 Speaker Select Switch
1 Input Level Select Switch
1 Input Level Adjustment Pot
