Bose 901 IV Series

If you wish to play you/ tape /eco/der without usin^ the
equalizer (for cooveniiohal speakers or headphor>es) and your
control amplifier has two tape monitor circurts. an ackjrtior^al
conrtectron procedure is required:
1. Connect "Y' connectors to both channels at the tape out¬
put connections of your tape recorder.
2 Connect one side of each "Y * connector as described in
Steps 2 and 3 of "Connecting Your Tape Recorder."
3. With the remaining output from each channel "Y" connec¬
tor, connect cables to the unused tape monitor input con¬
nections of Tape Monitor 2 found On your control amplifier.
4. To play your tape recorder with your dOis. place the tape
monitor of your 901 eouallzer in the monitor position (in) us¬
ing the TAPE MONITOR 1 circuit.
5. To play your tape recorder with convertiior^al speakers and
headphones, place the TAPE MONITOR 2 switch of your
control amplifier on. Your tape recorder will then be con¬
nected directly to your hlgh>fidellly system arv3 wilf play
without the equalizer.
NOTE: Contact your BOSE dealer conoerr>ir)g the availabili-
ly of "Y" conr>ector8 ar>d arry further connection advice.
6. C ONNECTING HEADPHONES AND CONVENTIONAL
SPEAKERS
It is important to realize mat the BOSE Active Equalizer ir
troduces substamial boost in the range below tOO Hz an
above 5,000 Hz to match the power response of the 90
Speakers. Consequently, conventional speakers or headphone;
If played with the equalizer in the circuit, will sound unnaturi
with both treble and base being emphasized.
MC^E IMPORTANTLY. HEADPHONES AND CONVENTIONAL
SPEAKERS MAY ACTUALLY BE DAMAGED IF PLAYED WITI
THE ACTIVE EQUALIZER IN THE CIRCUIT.
For this reason. It is important to switch the Active Equalize
out of the circuit by placing the tape monitor ewitch of you
control amplitler m the OFF or NORMAL position when piayin
conventional speakers or headphones with your high-fldeiit
system.
tAny ipMKer tysisni otMi Ihtn tn< OOSE IM or IV lyittm.
