Bose Acoustimass 15 Series II User Manual

11
Setting Up
Figure 6
Acoustimass
®
module to
receiver connections
Audio Output
Left
Rear
Center
Rear
Right
Rear
Left
Front
Center
Front
Right
Front
Audio Input
SURROUND SPEAKERS
R CENTER
FRONT SPEAKERS A
L
LFE/SUBWOOFER
OUT
R CENTERL
R CENTERL
FRONT SPEAKERS A
R CENTERL
Note: The center surround connection
is used only when a center rear
speaker is installed.
Note: Cables may be
separated or “unzipped”
as much as needed to
comfortably reach the
surround receiver
connections.
Thumbscrews
AM264924_00 _V.pdf • August 13, 2002

Bose Acoustimass 15 Series II Specifications

General

System Type	5.1 channel speaker system
Acoustimass Module	1
Impedance	4-8 ohms
Subwoofer Amplifier	Integrated
Connectivity Technology	Wired
Satellite Speakers	5
