Bose FreeSpace DS 40SE

16
MAIN PART LIST
DS 40SE Ceiling-Mount Bracket (included with loudspeaker), refer to Figure 7.
Item
Number
Description Part Number Qty. Note
1 CEILING MOUNTING PLATE, BLK - 1 4
CEILING MOUNTING PLATE, WHT -
2 COVER, BLK - 1 4
COVER, WHT -
3 MOUNTING ARM, BLK - 1 4
MOUNTING ARM, WHT -
4 SPEAKER ARM, BLK - 1 4
SPEAKER ARM, WHT -
5 WIRE HOLE COVER, BLK - 4 4
WIRE HOLE COVER, WHT -
6 ELECTRONICS MOUNT - 1 4
7 TERMINAL, SINGLE POLE - 2 4
8 TERMINAL, DUAL POLE - 2 4
9 WASHER, M5, DELRIN - 6 4
10 STRAIN RELIEF - 1 4
11 SCREW, M4X14, FLAT HEAD, CAPTIVE, SS, BLK
ZINC (PREASSEMBLED TO ITEM 2)
- 1 4
12 SCREW, M4X10, PAN HEAD, CAPTIVE, SS, BLK
ZINC (PREASSEMBLED TO ITEM 10)
- 1 4
13 SHOULDER SCREW, M4 - 3 4
14 SCREW, M4X10, PAN HEAD, SS, BLK ZINC - 1 4
15 WIRE, INSULATED, 18 AWG, 200 C - 4 4
16 SCREW, M4X16, PAN HEAD, SS, BLK ZINC - 1 4
17 WASHER, NYLON, 8MM OD, 3.5MM ID,
0.93MM THK
- 1 4
18 CARTON - 1 4
19 POLYBAG - 1 4
20 INSTALLATION INSTRUCTIONS - 1 4
21 WASHER, 4.25MM ID, 7.5MM OD, 0.75MM THK, SS - 4 4
22 SCREW, M4X18.5MM, PHILLIPS PAN HEAD, SS - 4 4
23 POLYBAG - 1 4
- SPEAKER ARM W / SCREW (INCLUDES METAL
SPEAKER ARM, 4 SCREWS, 4 WASHERS AND 1
SHOULDER SCREW ON ARM)
BLACK
WHITE
342184-011S
342184-012S
1
- COSMETIC COVER W / DOORS (INCLUDES
COVER W / MOUNTING SCREW AND 4 SURFACE-
RUN WIRE DOORS)
BLACK
WHITE
342186-011S
342186-012S
1
- HARWARE KIT (INCLUDES 4 DOORS, 1 STRAIN
RELIEF ASSY, 1 COSMETIC COVER SCREW,
1 ARM SHOULDER SCREW, 4 ARM SCREWS,
4 ARM WASHERS
BLACK
WHITE
342185-011S
342185-012S
1
