Bose FreeSpace DS 40SE - Mounting with Bose In-Wall Junction Box

18
MAIN PART LIST
FreeSpace
®
DS 40F, 8 Ohm Version (see Figure 8)
Item
Number
Description Bose
©
Part
Number
V
endor Part Number Qty. Note
1 FRONT BAFFLE, BLACK - 1468-6411+2 1 4
FRONT BAFFLE, WHITE - 1468-6412+2
2 DRIVER, 4.5 INCH 324015-001S 1527-0001+0 1
3 GASKET - 4149-0911+0 1 4
4 FLUSH ANCHOR, PC/ABS 324012-011S 4155-4351+1 3
5 SCREW, #8-32, WIRE
CLAMP
- 2AZZ-0007+ZZZZ 3 4
6 ACOUSTIC WOOL - 4149-7321+1 2.0 4
7 ENCLOSURE, REAR - 4135-9381+0 1 4
8 SCREW, MACHINE, BIND,
M6X12
- 2904-6012+3000 3 4
9 ACORN NUT, ANCHO
R
346479-011S 4135-9421+0 3
10 JUNCTION BOX COVER - 1404-6501+2 1 4
11 SCREW, B-TITE, 3X10MM,
BLK
- 2954-3010+3000 4 4
12 SIDE BRACKET - 4135-9371+0 3 4
13 S/T SCREW, 03X5 - 2940-3005+3000 6 4
14 JUNCTION BOX, MAIN - 4155-1961+2 1 4
15 TERMINAL WITH SCREWS 299572 SVC-
FCURL11+TERM
3
16 ANCHO
R
BOLT 327657-011S 4135-9411+1 3
17 FLUSH PORT - 4155-4361+0 1 4
18 PCB ASSY, PROTECTION 324014-001S SVC-SLAR11+PCB 1
19 GRILLE, BLACK, W/LOGO
GRILLE, WHITE, W/LOGO
299570
299571
SVC-FCURL11+GRIL
SVC-FCURL12+GRIL
1
20 PAD, PAINTING, SHIELD - 1451-0580+0 1 4
- WASHER, ANCHOR BOLT 346480-011S 2600-4012+1203 3
- LOGO ASSY, BLACK
LOGO ASSY, WHITE
303038-001
303038-002
SVC-SLAR11+LOGO
SVC-SLAR12+LOGO
1
