Bose FreeSpace DS 40SE - Page 29

29
Figure 10. FreeSpace
®
DS 40SE and DS 40F 70/100V Version Wiring Diagram
Figure 11. FreeSpace DS 40F 8 Ohm Version Wiring Diagram
6
1
2
3
4
5
A
8 ohmCOM 70.7/100V
70.7V 100V
0 V
5200-4933+1
T1
TRANS AUDIO 70.7/100V IN
2.5/5/10/20/40W O/P 8OHM
70.7V/100V IN
BLK.
RED.
GRN.
VOL.
BLU.
YEL.
WHT.
BRO.
4.5 INCH SPK
+
_
J1
VIN+
C1
6.8UF 50V 10%
J2
VOUT+
R1
6R 25W
PTC1
POLYSWITCH RXEF090
BLUE
40W
20W
10W
5W
NC
40W
20W
10W
0V
2.5W 5W
1527-0000+0
Remarks: C1 is not installed
Gray
*
CONNECT TO "+" PIN 1CONNECT TO "-" PIN 3
4.5 INCH SPK
+
_
J1
VIN+
C1
6.8UF 50V 10%
J2
VOUT+
R1
6R 25W
PTC1
POLYSWITCH RXEF090
1527-0000+0
Remarks: C1 is not installed
Gray
*
