Bose FreeSpace DS 40SE Service Manual

3
SPECIFICATIONS
Product Name: FreeSpace
®
DS 40SE Loudspeaker
Detailed Product Specifications
Power handling 40W
Nominal Impedance (transformer
bypass)
8 Ohms
Sensitivity (at 1W @ 1 m)
87 dB-SPL
Maximum SPL (pink noise @ 1 m @
rated power)
103 dB-SPL; 109 dB-SPL (Peak)
Frequency range (-3 dB) 80 Hz - 16 kHz
Beamwidth (-6 dB point, average 1 - 4
kHz)
125° H x 125° V
Driver complement One 4.5" (113.4mm) full-range driver
Construction features
Enclosure Injection-molded PC/ABS
Grille Powder-coated steel
Dimensions (inches/mm)
Loudspeaker only
6.9" D x 12.8" W x 6.3" H (175mm x
326mm x 159mm
)
Loudspeaker with wall mount bracket
9.4" D x 12.8" W x 6.3" H (238mm x
326mm x 159mm)
Weight (lb/kg)
Product (w/ wall mount bracket) 8.5lb (3.9kg)
Shipping (w/ wall mount bracket)
10.8lb (4.9kg)
Package contents
Loudspeaker, mounting bracket, and
installation guide
Finish
Textured black or white finish with a
contoured, powder-coated steel grille.
Both enclosure and grille can be painted.
Connectors
The included mounting bracket features
a three-terminal barrier strip. Optional
accessories provide a ceramic connector
and a thermal fuse for use when
required.
