Bose L1 1S User Manual

21
Main Part List
L1
®
Model 1S Line Array End Cap Assemblies (see Figure 10)
Item
Number
Description Bose
®
Part
Number
Vendor Part
Number
Qty. Note
END CAP #1 ASSEMBLY 304133 SVC-L211-
ENDCAP1
1
A
MS SCREW, M3X12, CSH.BK - 2901-3012+3000 8 4
B SCREW, B-TITE, FLAT-CS, M3X10 - 2951-3010+3000 8 4
C COVER, END CAP #1 - 1467-8101+0 1
D GASKET, END CAP, 83X82X1.5 - 4149-1141+0 3
END CAP #2 ASSEMBLY 304134
E CONNECTOR ASSY, MOLEX, 4
PIN
- 7012-6615+0 1
F COVER, END CAP #2 - 1467-8201+0 1
G SCREW, B-TITE, PAN, M3X10 - 2950-3010+3000 6 4
H PLATE, MOLEX, FLOATING - 4135-3511+0 1
I ENDCAP AIRPROOF SHEET - 4154-6841+1 2
J BUTYL TAPE - 9500-1100+0
D GASKET, END CAP, 83X82X1.5 - 4149-1141+0 3
A
MS SCREW, M3X12, CSH.BK - 2901-3012+3000 8 4
B SCREW, B-TITE, FLAT-CS, M3X10 - 2951-3010+3000 8 4
END CAP #3 ASSEMBLY 304135
G SCREW, B-TITE, PAN, M3X10 - 2950-3010+3000 6 4
H PLATE, MOLEX, FLOATING - 4135-3511+0 1
K PCB ASSY, CONNECTOR, 4 PIN - PCB-L211+CN4P 1
I ENDCAP AIRPROOF SHEET - 4154-6841+1 2
J BUTYL TAPE - 9500-1100+0
L COVER, END CAP #3 - 1467-8301+0 1
D GASKET, END CAP, 83X82X1.5 - 4149-1141+0 3
A
MS SCREW, M3X12, CSH.BK - 2901-3012+3000 8 4
B SCREW, B-TITE, FLAT-CS, M3X10 - 2951-3010+3000 8 4
- PLATE, METAL, ENDCAP #3 - 4135-7291+0 1
END CAP #4 ASSEMBLY 355487-
011S
M GASKET, LOWER COLLAR - 4149-1251+0 1
N FRAME, LOWER COLLAR - 4155-2301+0 1
O SHIM, CAVITY - 4155-2311+0 1
P SCREW, M3X8, C’SINK, BLK - 2901-3008+3000 2 4
Q SCREW, M3X8, C’SINK, FLT HD - 2951-3008+3000 1 4
R COVER, END CAP #4 - 1467-8401+0 1
S PCB ASSY, CONNECTOR, 10 PIN - PCB-
L211+CN10P
1
G SCREW, B-TITE, PAN, M3X10 - 2950-3010+3000 6 4
T PLATE, MOLEX, FIXED, 10 PIN - 4135-3531+0 1
A
MS SCREW, M3X12, CSH.BK - 2901-3012+3000 8 4
B SCREW, B-TITE, FLAT-CS, M3X10 - 2951-3010+3000 8 4
