Bose L1 1S User Manual

28
Electrical Part List
Resistors (continued)
Input/Output and DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R254 5.6K, RMG, 1/16W, 5%, 0603/1608 4723-562J 4
R255 4.7K, RMG, 1/16W, 1%, 0603/1608 4723-472J 4
R256 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J 4
R257 30.9K, RMG, 1/16W, 1%, 0603/1608 4723-3092 4
R258 5.6K, RMG, 1/16W, 5%, 0603/1608 4723-562J 4
R259 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J 4
R260 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J 4
R261 510R, RMG, 1/4W, 5%, 1206 4725-511J 4
R262 5.6K, RMG, 1/16W, 5%, 0603/1608 4723-562J 4
R263 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J 4
R264 510R, RMG, 1/4W, 5%, 1206 4725-511J 4
R265 5.6K, RMG, 1/16W, 5%, 0603/1608 4723-562J 4
R266 0R, RMG, 1/16W, 5%, 0603 4723-000J 4
R267 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J 4
R268 510R, RMG, 1/4W, 5%, 1206 4725-511J 4
R269 5.6K, RMG, 1/16W, 5%, 0603/1608 4723-562J 4
R270 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J 4
R271 510R, RMG, 1/4W, 5%, 1206 4725-511J 4
R272 5.6K, RMG, 1/16W, 5%, 0603/1608 4723-562J 4
R273 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J 4
R274 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J 4
R275 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J 4
R276 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J 4
R277 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J 4
R278 470R, RMG, 1/16W, 5%, 0603/1608 4723-471J 4
R279 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J 4
R280 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J 4
R281 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J 4
R282 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J 4
R283 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J 4
R284 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J 4
R285 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J 4
R286 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J 4
R287 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J 4
R288 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J 4
R289 5.6K, RMG, 1/16W, 5%, 0603/1608 4723-562J 4
R290 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R291 120R, RMG, 1/16W, 5%, 0603/1608 4723-121J 4
R292 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J 4
R293 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R294 1M, RMG, 1/16W, 5%, 0603/1608 4723-121J 4
R295 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J 4
R296 0R, RMG, 1/16W, 5%, 0603 4723-000J 4
R297 470R, RMG, 1/16W, 5%, 0603/1608 4723-471J 4
R298 15K, RMG, 1/16W, 1%, 0603/1608 4723-153A 4
R299 4.99K, RMG, 1/16W, 1%, 0603 4723-562A 4
R300 7.5K, RMG, 1/16W, 1%, 0603/1608 4723-752A 4
