Bose L1 1S User Manual

29
Electrical Part List
Resistors (continued)
Input/Output and DSP PCB Assembly
Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
R301 200K, RMG, 1/16W, 1%, 0603/1608 4723-204A 4
R302 7.5K, RMG, 1/16W, 1%, 0603/1608 4723-752A 4
R303 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J 4
R306 0R, RMG, 1/16W, 5%, 0603 4723-000J 4
R307 0R, RMG, 1/16W, 5%, 0603 4723-000J 4
R309 0R, RMG, 1/16W, 5%, 0603 4723-000JR 4
R310 470R, RMG, 1/16W, 5%, 0603/1608 4723-471J 4
R311 FERRITE-CORE, 0603, 2.5K, 50MA, 100MHZ,
HZ0603A252R
1808-0906 4
R312 FERRITE-CORE, 0603, 2.5K, 50MA, 100MHZ,
HZ0603A252R
1808-0906 4
R313 0R, RMG, 1/16W, 5%, 0603 4723-000J 4
R314 0R, RMG, 1/16W, 5%, 0603 4723-000J 4
R317 5.1K, RMG, 1/4W, 5%, 1206 4725-512J 4
R318 5.1K, RMG, 1/4W, 5%, 1206 4725-512J 4
R319 5.1K, RMG, 1/4W, 5%, 1206 4725-512J 4
R320 5.1K, RMG, 1/4W, 5%, 1206 4725-512J 4
R500 0R, RMG, 1/16W, 5%, 0603 4723-000J 4
R501 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
Reference
Designator
Description
V
endor Part
Number
Note
C101 1000pF, CC, 50V, 10%, 0603, X7
R
150F-102KAC 4
C102 1000
p
F, CC, 50V, 10%, 0603, X7
R
150F-102KAC 4
C103 0.1uF, CC, 50V, 10%, 0603, X7R 150F-104KAC 4
C104 0.01uF, CC, 50V, 10%, 0603, X7R 150F-103KAC 4
C105 1000pF, CC, 50V, 10%, 0603, X7
R
150F-102KAC 4
C106 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C107 0.01uF, CC, 50V, 10%, 0603, X7R 150F-103KAC 4
C108 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C109 0.1uF, CC, 50V, 10%, 0603, X7
R
150F-104KAC 4
C110 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C111 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C114 100pF, CC, 50V, 5%, 0603, C0G 150F-101JAC 4
C115 100
p
F, CC, 50V, 5%, 0603, C0G 150F-101JAC 4
C116 100pF, CC, 50V, 5%, 0603, C0G 150F-101JAC 4
C117 100pF, CC, 50V, 5%, 0603, C0G 150F-101JAC 4
C118 100pF, CC, 50V, 5%, 0603, C0G 150F-101JAC 4
C119 100pF, CC, 50V, 5%, 0603, C0G 150F-101JAC 4
C126 100pF, CC, 50V, 5%, 0603, C0G 150F-101JAC 4
C127 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C129 1000
p
F, CC, 50V, 10%, 0603, X7
R
150F-102KAC 4
C130 1000pF, CC, 50V, 10%, 0603, X7R 150F-102KAC 4
C134 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C135 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
C136 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106MGJ 4
