Bose L1 1S User Manual

40
Electrical Part List
Resistors (continued)
Reference
Designator
Description
V
endor Part
Number
Note
R
55 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R56 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R57 47K, RMG, 1/16W, 1%, 0603/1608 4723-473A 4
R58 2.2K, RMG, 1/16W, 1%, 0603/1608 4723-222A 4
R59 47K, RMG, 1/16W, 1%, 0603/1608 4723-473A 4
R60 1.8K, RMG, 1/16W, 1%, 0603/1608 4723-182A 4
R61 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R62 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R63 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R64 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A 4
R65 47K, RMG, 1/16W, 1%, 0603/1608 4723-473A 4
R66 2.2K, RMG, 1/16W, 1%, 0603/1608 4723-222A 4
R67 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R68 560R, RMG, 1/16W, 1%, 0603 4723-561A 4
R69 2.7K, RMG, 1/16W, 1%, 0603/1608 4723-272A 4
R70 2.7K, RMG, 1/16W, 1%, 0603/1608 4723-272A 4
R71 2.7K, RMG, 1/16W, 1%, 0603/1608 4723-272A 4
R72 2.7K, RMG, 1/16W, 1%, 0603/1608 4723-272A 4
R75 2.2R, RMG, 1/16W, 5%, 0603/1608 4723-2R2J 4
R76 2.2R, RMG, 1/16W, 5%, 0603/1608 4723-2R2J 4
R77 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R78 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R79 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R80 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R81 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R83 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R84 560R, RMG, 1/16W, 1%, 0603 4723-561A 4
R85 560R, RMG, 1/16W, 1%, 0603 4723-561A 4
R86 560R, RMG, 1/16W, 1%, 0603 4723-561A 4
R87 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R88 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R89 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
R90 2.2R, RMG, 1/16W, 5%, 0603/1608 4723-2R2J 4
R91 2.2R, RMG, 1/16W, 5%, 0603/1608 4723-2R2J 4
R92 2.2K, RMG, 1/16W, 1%, 0603/1608 4723-222A 4
R93 2.2K, RMG, 1/16W, 1%, 0603/1608 4723-222A 4
R94 2.2K, RMG, 1/16W, 1%, 0603/1608 4723-222A 4
R95 2.2K, RMG, 1/16W, 1%, 0603/1608 4723-222A 4
R100 100K, RMG, 1/10W, 1%, 0805 4720-104A 4
R101 100K, RMG, 1/10W, 1%, 0805 4720-104A 4
R102 220K, RMG, 1/10W, 5%, 0805 4720-224J 4
R103 220K, RMG, 1/10W, 5%, 0805 4720-224J 4
R104 220K, RMG, 1/10W, 5%, 0805 4720-224J 4
R105 82K, RMG, 1/10W, 5%, 0805 4720-823J 4
R106 82K, RMG, 1/10W, 5%, 0805 4720-823J 4
R200 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R202 1.5K, RMG, 1/16W, 1%, 0603/1608 4723-152A 4
