Bose L1 1S User Manual

41
Electrical Part List
Resistors (continued)
Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
R203 470R, RMG, 1/16W, 5%, 0603/1608 4723-471J 4
R204 22R, RMG, 1/10W, 5%, 0805 4720-220J 4
R205 22R, RMG, 1/10W, 5%, 0805 4720-220J 4
R206 0.12R, RMG, 1/4W, 5%, 1206 4725-R12J 4
R207 0.12R, RMG, 1/4W, 5%, 1206 4725-R12J 4
R208 47K, RMG, 1/10W, 5%, 0805 4720-473J 4
R209 47K, RMG, 1/10W, 5%, 0805 4720-473J 4
R210 47K, RMG, 1/10W, 5%, 0805 4720-473J 4
R212 100R, RMG, 1/10W, 5%, 0805 4720-101J 4
R213 0.12R, RMG, 1/4W, 5%, 1206 4725-R12J 4
R214 0.12R, RMG, 1/4W, 5%, 1206 4725-R12J 4
R215 47K, RMG, 1/10W, 5%, 0805 4720-473J 4
R217 470R, RMG, 1/16W, 5%, 0603/1608 4723-471J 4
R218 10R, RMG, 1/10W, 1%, 0805 4720-100J 4
R219 10R, RMG, 1/10W, 1%, 0805 4720-100J 4
R222 1R, RMG, 1/16W, 5%, 0603 4723-1R0J 4
R223 1R, RMG, 1/16W, 5%, 0603 4723-1R0J 4
R230 10R, RMG, 1/10W, 1%, 0805 4720-100A 4
R231 10R, RMG, 1/10W, 1%, 0805 4720-100A 4
R232 36K, RMG, 1/16W, 1%, 0603 4723-363A 4
R233 36K, RMG, 1/16W, 1%, 0603 4723-363A 4
R234 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R236 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A 4
R238 36K, RMG, 1/16W, 1%, 0603 4723-363A 4
R239 36K, RMG, 1/16W, 1%, 0603 4723-363A 4
R240 47K, RMG, 1/16W, 1%, 0603/1608 4723-473A 4
R241 36K, RMG, 1/16W, 1%, 0603 4723-363A 4
R242 5.1K, RMG, 1/16W, 1%, 0603/1608 4723-512A 4
R243 5.1K, RMG, 1/16W, 1%, 0603/1608 4723-512A 4
R290 100K, RMG, 1/16W, 1%, 0603 4723-104A 4
R291 100R, RMG, 1/16W, 1%, 0603 4723-101A 4
Reference
Designator
Description
V
endor Part
Number
Note
C1 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C2 0.47uF, CC, 16V, 10%, 0805/2012 150D-474KBDL 4
C3 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C4 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C5 2700pF, CC, 50V, 10%, 0805, 1.2X2.0 150F-272KBD 4
C6 47pF, CTC, 0/60, 5%, 0603, 0.8X1.6 15CH-470JAC 4
C7 330pF, CTC, 0/60, 5%, 0603, 0.8X1.6 15CH-331JAC 4
C8 0.22uF, CC, 16V, 10%, 0805, 1.2X2.0 150D-224KBD 4
C9 220
p
F, CTC, 0/30, 100V, 5%, 1206 15CG-221JCFH 4
C10 3300pF, CC, 50V, 10%, 0805, 1.2x2.0 150F-332KBD 4
C12 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C13 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
SMPS / Power Amplifier PCB Assembly
