Electrical Part List
Capacitors (continued)
Reference
Designator
Description
V
endor Part
Number
Note
C14 4.7uF, CC, 16V, 20%, 1206, SMD, Y5V 150D-475ZCF 4
C15 0.47uF, CM, 100V, 10%, RBT, 9.5X7.2 153H-474KRN 4
C16 0.33uF, CM, 100V, 5%, RBT, 7.2 X9.5,
METALLI ZED, FARATRON
153H-
334JNRM4
4
C17 3300pF, CC, 50V, 10%, 0805, 1.2x2.0 150F-332KBD 4
C18 2700pF, CC, 50V, 10%, 0805, 1.2X2.0 150F-272KBD 4
C19 680pF, CTC, 0/30, 5%, 0805, 1.2x2.5 15CG-681JBD 4
C20 0.22uF, CC, 16V, 10%, 0805, 1.2X2.0 150D-224KBD 4
C21 4.7uF, CC, 16V, 20%, 1206, SMD, Y5V 150D-475ZCF 4
C22 0.47uF, CM, 100V, 10%, RBT, 9.5X7.2 153H-474KRN 4
C23 220
p
F, CTC, 0/30, 100V, 5%, 1206 15CG-221JCFH 4
C24 0.33uF, CM, 100V, 5%, RBT, 7.2 X9.5,
METALLI ZED, FARATRON
153H-
334JNRM4
4
C25 2200pF, CC, 50V, 10%, 0603, X7R 150F-222KAC 4
C26 2200pF, CC, 50V, 10%, 0603, X7R 150F-222KAC 4
C27 47pF, CTC, 0/60, 5%, 0603, 0.8X1.6 15CH-470JAC 4
C28 330
p
F, CTC, 0/60, 5%, 0603, 0.8X1.6 15CH-331JAC 4
C29 0.47uF, CC, 16V, 10%, 0805/2012 150D-474KBDL 4
C31 2.2uF, CC, 50V, 10%, 1206, X7R, MURATA 150F-225KCFM 4
C32 2.2uF, CC, 50V, 10%, 1206, X7
R
, MURAT
A
150F-225KCFM 4
C33 2.2uF, CC, 50V, 10%, 1206, X7R, MURATA 150F-225KCFM 4
C34 2.2uF, CC, 50V, 10%, 1206, X7R, MURATA 150F-225KCFM 4
C37 2.2uF, CC, 50V, 10%, 1206, X7R, MURATA 150F-225KCFM 4
C38 2.2uF, CC, 50V, 10%, 1206, X7
R
, MURAT
A
150F-225KCFM 4
C39 2.2uF, CC, 50V, 10%, 1206, X7R, MURATA 150F-225KCFM 4
C40 2.2uF, CC, 50V, 10%, 1206, X7R, MURATA 150F-225KCFM 4
C41 0.01uF, CC, 100V, 20%, 0805 150H-103MBD 4
C43 2200uF, CE, 50V, 20%, RL, 18X31, 105C 157F-228M7$T 4
C44 2200uF, CE, 50V, 20%, RL, 18X31, 105C 157F-228M7$T 4
C45 220pF, CTC, 0/60, 5%, 0603, 0.8X1.6 15CH-221JAC 4
C46 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C47 1u
F
, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C48 2.2uF, CM, 63V, 10%, RBT, 7.2X11X6,
METALLIZED
153I-225KNUM 4
C49 2.2uF, CM, 63V, 10%, RBT, 7.2X11X6,
METALLIZED
153I-225KNUM 4
C51 1000pF, CTC, 0/30, 5%, 0805, 1.2x2.5 15CG-102JBD 4
C52 1000pF, CTC, 0/30, 5%, 0805, 1.2x2.5 15CG-102JBD 4
C53 1000pF, CTC, 0/30, 5%, 0805, 1.2x2.5 15CG-102JBD 4
C54 1000
p
F, CTC, 0/30, 5%, 0805, 1.2x2.5 15CG-102JBD 4
C56 1000pF, CTC, 0/30, 5%, 0805, 1.2x2.5 15CG-102JBD 4
C57 1000pF, CTC, 0/30, 5%, 0805, 1.2x2.5 15CG-102JBD 4
C58 1000pF, CTC, 0/30, 5%, 0805, 1.2x2.5 15CG-102JBD 4
C59 1000pF, CTC, 0/30, 5%, 0805, 1.2x2.5 15CG-102JBD 4
C60 220pF, CTC, 0/60, 5%, 0603, 0.8X1.6 15CH-221JAC 4
C61 220pF, CTC, 0/60, 5%, 0603, 0.8X1.6 15CH-221JAC 4
C62 220pF, CTC, 0/60, 5%, 0603, 0.8X1.6 15CH-221JAC 4
SMPS / Power Amplifier PCB Assembly
