Bose L1 1S User Manual

44
Electrical Part List
Capacitors (continued)
Inductors
Reference
Designator
Description
V
endor Part
Number
Note
F200 FERRITE-CORE, 1206, 0.6K, 1.5
A
, 100MHZ,
MI1206K601R
1808-0907 4
L1 10uH, CHOKE, COIL, 10%, 7A, T94-2 1806-3899 4
L3 10uH, CHOKE, COIL, 10%, 7A, T94-2 1806-3899 4
L8 CHOKE, COMMON MODE, 2X16UH, 8A, FT50-
43
1806-3913 4
L100 CHOKE, COMMON MODE ,2X10MH, 3A, TC-
2510
1806-3934 4
L101 CHOKE, COMMON MODE ,2X10MH, 3A, TC-
2510
1806-3934 4
L200 FERRITE-CORE, 0805, 1000OHM, 100MHZ, 1A 1808-0904 4
L201 FERRITE-CORE, 0805, 1000OHM, 100MHZ, 1A 1808-0904 4
L202 FERRITE-CORE, 0805, 1000OHM, 100MHZ, 1A 1808-0904 4
L204 FERRITE-CORE, 0805, 1000OHM, 100MHZ, 1
A
1808-0904 4
Diodes
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C218 4700pF, CC, 250VAC, 10%, SMD, X7R 150R-472KKIM 3, 4
C219 1uF, CC, 50V, 10%, 1206, X7R, MURATA 150F-105KCFM 4
C220 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C221 1uF, CC, 10V, 20%, 0603, 332181050R1 150C-105ZAC 4
C222 470uF, CE, 35V, 20%, RL, 10X20, 105C 157Q-477MS9T 4
C223 470uF, CE, 35V, 20%, RL, 10X20, 105C 157Q-477MS9T 4
C226 0.15uF, CC, 50V, 10%, 0805 150F-154KBD 4
C227 0.15uF, CC, 50V, 10%, 0805 150F-154KBD 4
C301 220pF, CTC, 0/30, 100V, 5%, 1206 15CG-221JCFH 4
C302 220pF, CTC, 0/30, 100V, 5%, 1206 15CG-221JCFH 4
C303 0.01uF, CC, 100V, 20%, 0805 150H-103MBD 4
C304 0.01uF, CC, 100V, 20%, 0805 150H-103MBD 4
C305 0.1uF, CC, 100V, 10%, 0805, X7R 150H-104KBD 4
C306 0.1uF, CC, 100V, 10%, 0805, X7R 150H-104KBD 4
C307 0.1uF, CC, 100V, 10%, 0805, X7
R
150H-104KBD 4
C308 0.1uF, CC, 100V, 10%, 0805, X7R 150H-104KBD 4
C309 0.1uF, CC, 100V, 10%, 0805, X7R 150H-104KBD 4
C310 0.1uF, CC, 100V, 10%, 0805, X7
R
150H-104KBD 4
C311 0.1uF, CC, 100V, 10%, 0805, X7R 150H-104KBD 4
C312 0.1uF, CC, 100V, 10%, 0805, X7R 150H-104KBD 4
Reference
Designator
Description
V
endor Part
Number
Note
D1 BAS321, 200V, 250MA, 50NS, SOD323 480S-3210 4
D2 BAS321, 200V, 250MA, 50NS, SOD323 480S-3210 4
D3 BAS321, 200V, 250MA, 50NS, SOD323 480S-3210 4
D4 BAS321, 200V, 250MA, 50NS, SOD323 480S-3210 4
