Bose L1 1S User Manual

45
Electrical Part List
Diodes (continued)
Transistors
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
D5 BAS321, 200V, 250MA, 50NS, SOD323 480S-3210 4
D6 BAS321, 200V, 250MA, 50NS, SOD323 480S-3210 4
D7 BAS321, 200V, 250MA, 50NS, SOD323 480S-3210 4
D8 BAS321, 200V, 250MA, 50NS, SOD323 480S-3210 4
D9 BAS321, 200V, 250MA, 50NS, SOD323 480S-3210 4
D10 BAS321, 200V, 250MA, 50NS, SOD323 480S-3210 4
D14 BAS321, 200V, 250MA, 50NS, SOD323 480S-3210 4
D100 GBU8K, BRIDGE, 800V, 8A, RL 4840-9218 4
D200 US1J, 600V, 1A, 75NS, SOD124 480U-S1J0 4
D201 BAS316, 75V, 0.5A, SOD323, SM 480S-3160 4
D202 BAS316, 75V, 0.5A, SOD323, SM 480S-3160 4
D203 BAS316, 75V, 0.5A, SOD323, SM 480S-3160 4
D204 BAS316, 75V, 0.5A, SOD323, SM 480S-3160 4
D205 12CWQ10FNTRBF, RECTIFIER, 100V, 12A,
DPAK, SMDIR
4840-9213 4
D206 12CWQ10FNTRBF, RECTIFIER, 100V, 12A,
DPAK, SMDIR
4840-9213 4
D207 12CWQ10FNTRBF, RECTIFIER, 100V, 12A,
DPAK, SMDIR
4840-9213 4
D208 12CWQ10FNTRBF, RECTIFIER, 100V, 12A,
DPAK, SMDIR
4840-9213 4
D209 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190 4
D210 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190 4
D211 BAS316, 75V, 0.5A, SOD323, SM 480S-3160 4
D212 BAS316, 75V, 0.5A, SOD323, SM 480S-3160 4
D216 BAS316, 75V, 0.5A, SOD323, SM 480S-3160 4
D217 BAS316, 75V, 0.5A, SOD323, SM 480S-3160 4
D218 BAS316, 75V, 0.5A, SOD323, SM 480S-3160 4
D290 BAS316, 75V, 0.5A, SOD323, SM 480S-3160 4
Z200 ZENER, 4JB15, 1/2W, 15V, 0.3V, BZX8,
SOD323 F, SM, PHILIPS
4837-1503 4
Z201 ZENER, 4JC11, 1/2W, 11V, 0.6V, BZX8,
SOD323 F, SM, PHILIPS
4837-1103 4
Reference
Designator
Description
V
endor Part
Number
Note
Q1 MOSFET, N-CHANNEL, FDD368, 2_NL, 100V,
32A, TO-252AA
4903-6820 4
Q2 MOSFET, N-CHANNEL, FDD368, 2_NL, 100V,
32A, TO-252AA
4903-6820 4
Q3 MOSFET, N-CHANNEL, FDD368, 2_NL, 100V,
32A, TO-252AA
4903-6820 4
Q4 MOSFET, N-CHANNEL, FDD368, 2_NL, 100V,
32A, TO-252AA
4903-6820 4
Q5 BC856S, PNP PAIR, 60V, SOT363 4858-56S0 4
Q6 BC856S, PNP PAIR, 60V, SOT363 4858-56S0 4
