Bose L1 1S User Manual

46
Electrical Part List
Transistors (continued)
Integrated Circuits
Reference
Designator
Description
V
endor Part
Number
Note
IC1 HALF BRIDGE DRIVER, LV4970M, SO-16 3132-3051
IC2 HALF BRIDGE DRIVER, LV4970M, SO-16 3132-3051
IC3 ANALOG 2CH CONTROLLER, LV4930M,
QUAD44
3132-3061
IC4 MC33078DR2G, OP-AMP, SO-8 3132-2711
IC200 L6571BD013TR, HALF BRIDGE DRIVER, SO8
(BOSE® PART NUMBER 291328
)
3132-3071
Miscellaneous
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
Q200 MOSFET, N-CH, 500V, 11A, STB12NM50ND,
D2PAK, SM, ST
4905-0ND0 4
Q201 MOSFET, N-CH, 500V, 11A, STB12NM50ND,
D2PAK, SM, ST
4905-0ND0 4
Q202 REGULATOR, 5V, LM78L05ACM, SO-8 3131-3390 4
Q203 BCP56-10, NPN, SOT223 485C-P560 4
Q204 REGULATOR, 250MA, LM79L05, SO8 3132-3091 4
Q205 NPN/PNP PAIR, FFB2227A, SC70-6 4852-27A0 4
Q206 NPN/PNP PAIR, FFB2227A, SC70-6 4852-27A0 4
Q207 BC856S, PNP PAIR, 60V, SOT363 4858-56S0 4
Q208 MOSFET, N-CH, 60V, 115MA, 2N7002,
SOT-23, SM
4907-0020 4
Q209 MOSFET, N-CH, 60V, 115MA, 2N7002,
SOT-23, SM
4907-0020 4
Q210 BC856S, PNP PAIR, 60V, SOT363 4858-56S0 4
Q211 BC846B, SOT23, PHILIPS, SMD 4858-46B0 4
Q290 PUMZ1, NPN/PNP PAIR, SOT363 485U-MZ10 4
Reference
Designator
Description
V
endor Part
Number
Note
CON300 WAFER, 3P, P7, .92/11.88, STRAIGHT 2101-3097 4
CON301 WAFER, 4P, P3.96, STRAIGHT, MALE 2101-3053 4
F100 FUSE, T6.3A/125V, TE5-T, PSE/UL 5120-1094 3,4
J301 6 PIN, W
F
2102-060S 4
J302 6 PIN, WF 2102-060S 4
J303 WAFER, 3P, P2.0, ST, MALE 2101-3008 4
MOV VARISTOR, 320V, 10%, SIOV-S10K320 4735-0003 3,4
N1 THERMISTER, NTC, 100K, 5%, B5,
7620C0104J162, 0805, EPCOS
5202-0019 4
N100 THERMISTER, NTC 5 0HM, 4A, NIOSP005L,
UL/CSA/VDE
5202-0010 4
