Bose SoundLink Mini

2
Contents
Product Descripton 3
Safety Information 3
Electrostatic Discharge Sensitive (ESDS) Device Handling 4
Warranty 4
Part List Notes 4
Packaging Part List, SoundLink
®
Mini II 5
Figure 1. SoundLink Mini II, Packaging View 6
Main Part List, SoundLink Mini II 7
Figure 2. SoundLink Mini II Main Assembly, Exploded View 8
Electrical Parts List 9-20
Disassembly Procedure 21-25
Assembly Key Points 26-29
Using TAP Commands 30
Test Procedures 31-33
Remanufacturing TAP Commands 34
Service Manual Revision History 35
