8
Dolby Pro Logic and Dolby Digital
Line-Level System Connection
Using the line-level connection to the Micro80pv subwoofer generally results in a cleaner system
sound, since the receiver no longer has to reproduce the difficult low bass information that can push
it into audible distortion (also known as clipping).
Dolby Pro Logic Systems
Use an RCA cable (not included) to connect your receiver’s Sub out jack to the Line in jack on the
Micro80pv, as shown below.
Set the center and surround channel modes to “NORMAL.” This will send all the bass to
the subwoofer.
Main
speakers
Center
speaker
RightLeft
Left Micro80x
Receiver
Right Micro80x
Micro80c
Surround
speakers
RightLeft
Left Micro80e Right Micro80e
LR
Speaker level in
Micro80pv Subwoofer
Line in
Sub out
