Boston Whaler 190 Montauk User Manual

2-4 190 Montauk
Section 2 • General Information
R
Overall Length 19’0” 5.79 m
Bridge Clearance (no top) 5’0” 1.52 m
Bridge Clearance (Sun- Top) 7’ 1 1/2” 2.17 m
Beam 8’0” 2.44 m
Draft, (Hull only)
1
12” .30 m
Weight (dry, no engine) 1900 lbs. 862 kg
Swamped Capacity 4200 lbs 1905 kg
Specifications & Dimensions
(Specified measurements are approximations and are subject to variance.)
1
Optional equipment and loading of the boat will affect the draft measurements. Follow the recommendations listed
on your capacity plate regarding the maximum amount of weight your boat can safely carry.
2
Exceeding this weight will affect the boat’s performance. DO NOT Exceed the weights listed on the capacity plate.
Dimensions & Clearances
Fig. 2.4.1
19’ 0”
(5.79 m)
8’0”
(2.44 m)
12” (.30 m)
Maximum Engine Weight 4 10 lbs. 186 kg
MaximumWeight, 2500 lbs 1134 kg
(passengers, engine(s), gear
2
)
Persons 8 8
Maximum Horsepower 115 HP 85 kw
Minimum Horsepower 90 HP 67 kw
Fuel Capacity 60 Gal. 227 L
Shown with Sun Top option
5’ 0”
(1.52 m)
7’ 1.5”
(2.17 m)

Boston Whaler 190 Montauk Specifications

General

Beam	8' 0"
Weight	1, 900 lbs
Maximum Horsepower	150 HP
Seating Capacity	8
Weight (Dry)	1, 900 lbs
Deadrise at Transom	16°
Beam (Third Value)	8' 0"
Weight (Third Value)	1, 900 lbs
Fuel Capacity	60 gal
Fuel Capacity (Second Value)	60 gal
Length Overall	19' 4"
