ASEMBLE INSTRUCTION
10. Connect the PTO drivline:
1 Raise the input shaft guard.
2 Check that the driveline telescopes
easily and that the shield rotates
freely.
3 Attach the driveline to the chipper
input shaft by depressing the lock
pin, slide yoke over the shaft and
pushing on the yoke until the lock
pin clicks into position.
NOTE
Be sure the yoke with the shear pin is
attached to the machine shaft.
4. Lower the guard to cover the input
shaft.
11. Depress handle on discharge chute latch
and turn assembly to its desired position.
Turn until latch seats in its detent.
