www.etractorimplements.com 41
SERVICE AND MAINTENANCE
100 Hours
1. Grease the hydraulic feed system:
a. Roller bearings.
b. Pivot bushing.
Left Side
Right Side
2. Grease rotor bearings on BX52 and BX62
models.
IMPORTANT
Do not over grease.
WARNING Front
Machine is shown with guard re- moved or rotor
cover opened for illustrative purposes only. Do
not operate machine with guard removed or
cover opened.
Rear
