Bowell BX52 - Page 52

www.etractorimplements.com 50
PARTS LIST
BX62R.001
No.
Part No.
Name & Specification
Qty
1
BX62.002
Discharge pipe components
1
2
BX62.012
Shell-on weldment
1
3
BX62.013
Cutter weldment
1
4
BX62R.003
Hopper assembly
1
5
BX62.011
Base weldment
1
6
BX62.014
Side knife weldment
1
7
BX62.102
PTO cover
1
8
BX62.101
Bracket
1
9
HBF14A1.25A45
Bolts M14 * 1.25 * 45
8
10
PW14
Washer 14
4
11
BUCF210
UCF210 bearing seat
2
12
HBF10A25
The M10 * 25
2
13
PW10
Flat pad 10
2
14
NN10
Locknut 10
2
15
HBF12A1.25A30
bolts M12 * 1.25 * 30
16
16
SW12
Spring Washer 12
16
17
BX62.103
Movable Knife
4
18
EFH175.105
Lower pin
2
19
SW22
Spring Washer 22
2
20
PW22
Washer 22
2
21
HN22
Hex nuts 22
2
22
HBF12A1.25A35
Bolt M12 * 1.25 * 35
2
23
PW12
Washer 12
2
24
NN12
Locking nut M12
4
25
PW12A3
washer 12 * 3
3
26
BX62.104
Fixed knife
1
27
HBF8A65
Bolt M8 * 65
2
28
BX62.120
Pneumatic spring
2
29
NN8
Locking nut M8
2
30
HBF12A35
Bolt M12 * 35
4
31
SP11
Lock pin 11
3
32
BX52.101
Upper pon
1
33
HN10
Hex nuts 10
2
34
SW10
Spring washer 10
2
35
RP4
R pin 4
1
