Bowell BX52 - Page 58

www.etractorimplements.com 56
PARTS LIST
No
Part No.
Name & Specification
QTY
1
02.BX52.00.001
output chute cap locker
1
2
03.02.6182.M8
locking nut M8
6
3
02.BX52.00.003
output chute
1
4
02.BX52.00.004
output chute turning locker
1
5
03.01.5781.M8x30
full thread hexagon head bolt M8x30
1
6
02.BX52.00.006
steel ball locker Φ8×(30~45)
2
7
03.01.5781.M6x20
full thread hexagon head bolt M6x20
4
8
02.BX52.00.008
plate 1 of plastic transparent curtain
1
9
02.BX52.00.009
plastic transparent curtain (1.5×410×425)
1
10
02.BX52.00.010
plate 2 of plastic transparent curtain
1
11
03.02.6182.M6
locking nut M6
4
12
02.BX52.00.012
lock pin Φ10-16×30
1
13
03.02.6170.M3
common nut M3
4
14
03.03.97,1.Φ3
flat washer Φ3
4
15
03.04.93.Φ3
spring washer Φ3
4
16
03.01.818.M3x10
Cross recessed pan head screws M3x10
4
17
02.BX52.00.017
upper feeding chute
1
18
03.01.5781.M14x40
full thread hexagon head bolt M14x40
2
19
03.02.6182.M14
locking nut ,M14
2
20
03.02.6182.M10
locking nut ,M10
21
21
03.01.70,3.M10x30
hexagon socket countersunk head cap screws M10x30
16
22
02.BX52.00.022
rotor
1
23
02.BX52.00.023
rotor knife
4
24
03.05.7809.UCF208
inserted bearing with housing UCF208
2
25
02.BX52.00.025
counter knife
1
26
03.03.97,1.Φ8
flat washer Φ8
3
27
03.04.93.Φ8
spring washer Φ8
3
28
03.01.5781.M8x30
full thread hexagon head bolt M8x30
3
29
02.BX52.00.029
middle feeding chute
1
30
02.BX52.00.030
bearing cover
1
31
03.01.5781.M10x25
full thread hexagon head bolt M10x25
5
32
02.BX52.00.032
frame
1
33
02.BX52.00.033
branch breaker
1
34
02.BX52.00.034
lower hitch
2
35
03.07.DIN11023.Φ56
linch pin
3
36
02.BX52.00.036
Cat 2 lower bushing, Φ22xΦ28-45
2
37
03.04.93.Φ22
spring washer Φ22
2
38
03.02.6182.M12
locking nut ,M12
5
39
03.01.5781.M12x30
full thread hexagon head bolt M12x30
5
