Boya BY-MM1+ - Connecting to Cameras and Recorders

Attach the microphone to cameras,
camcorders, audio recorders and other
audio or video recording devices.
1. Turn counter-clockwise to loosen the screw.
2. Slide the microphone onto the camera’s hot shoe.
3. Turn clockwise to tighten the screw to stabilize on the
shoe mount.
NOTE:
The headphone jack of BY-MM1+ cannot be used to monitor
(playback/real-time monitoring is not supported) when
connecting to camera, camcorder and recorder. If you need
to monitor the audio just recorded, it requires your camera,
camcorder and recorder have a built-in headphone jack.
