bp pulse home - Configuring WiFi for Pulse Home; Initiating WiFi Setup; Entering Network Credentials; Saving Settings and Rebooting

Congure WiFi
2
Your bp pulse home will then set up a WiFi Access
Point. The WiFi Access Point network name will be
‘bppulse-’ followed by your charger’s serial number
at the end. For example, if the serial number of
your charger is ‘PH1234567’, the WiFi Access Point
network name will be ‘bppulse-PH1234567’.
6
Select the Conguration tab to congure your
unit to connect to your home WiFi network.
3
On your mobile device, go to the WiFi settings
and select the Access Point network name as
detailed above.
7
Enter the network name and password
of the home WiFi Network.
4
Once successfully connected to the charger’s WiFi
Access Point, you will be automatically redirected to
the log in page. Otherwise, open a web browser on
your mobile device and enter ’10.0.0.1’ into the web
browser’s address bar. You may be asked to accept
self-signed certicates.
If certicates display:
· First click on ’Advanced’
· Then click on ’proceed to xxxxx (unsafe)’
8
Select the ‘Save’, to save changes.
10
Once your charger has completed its boot-up
sequence, it will connect to your home WiFi
network and you should be able to control your
charger using the bp pulse app and portal.
9
Select ‘Reboot Device’ to apply congurations, the
charger will then reboot. Please allow 5 minutes for
the charger to complete the reboot process.
1
Press and hold down the function
button for six seconds.
5
Enter the login details and press ‘Connect’.
The default log in credentials are: Username: ’User’.
Password will have been provided prior to you
by bp pulse.
pulse home User Guide
13
