Please note that the minimum gas inlet pressure should be at least 1.13KPa (Natural Gas) and 2.75KPa
(Propane). Gas pressure must be checked when all other equipment on the same line is turned ON high.
Table 2: Standard Model General Information
*
Denotes Minimum
Overall Dimensions – Custom made appliances
Height overall splashback : 950mm - 1,300mm + adjustable legs.
Height Plinth Mount : 980mm.
Width : 1,840mm minimum with 4 pans. (NC-6)
2400mm minimum with 4 pans ( NC-9)
Depth : 800mm minimum.
Figure 1: Plumbing Connections -Verro NC-6 (800 deep)
