11
PCD24B
PARTS
KEY
ITEM DESCRIPTION QTY.
1 HOUSING 1
2 BRAKE CYLINDER 1
3 MOTOR SUPPORT 1
4 OUTPUT SHAFT 1
5 SEAL 1
6 TAPERED BEARING CONE 1
7 TAPERED BEARING CUP 1
8 TAPERED BEARING CONE 1
9 TAPERED BEARING CUP 1
10 O-RING OR GASKET
(depending on motor option)
1
11 O-RING 1
12 SPLIT RING 1
13 PLANET CARRIER 1
14 PLANET GEAR 3
15 PLANET GEAR SHAFT 3
16 THRUST RACE 6
17 ROLLER BEARING 6
18 ROLLPIN 3
19 BEARING SPACER 3
20 SUN GEAR 1
21 THRUST WASHER 1
22 SPRING 12
23 PRESSURE PLATE 1
24 SPACER PLATE 2
25 BRAKE PISTON 1
26 BRAKE PISTON SEAL 1
27 FRICTION DISC 7
28 STEEL DISC 8
29 O-RING 1
30 BACKUP RING 1
31 BRAKE COUPLING 1
32 LOCKWASHER 4
33 CAPSCREW (HEX HEAD) 4
34 O-RING 2
35 MOTOR 1
36 BRAKE VALVE BLOCK 1
37 CAPSCREW 4
38 REDUCER BUSHING 1
39 VENT PLUG 1
40 PIPE PLUG 4
41 CAPSCREW (SOCKET HEAD) 6
42 COUNTERBALANCE VALVE CARTRIDGE 2
43 HOSE ASSEMBLY 1
44 ELBOW FITTING 1
45 CAPSCREW 2
46 LOCKWASHER 2
47 ELBOW FITTING 1
50 CAPSTAN PIN (not used with fixed capstan) 1
51 CAPSCREW (HEX HEAD - fixed capstan ONLY) 1
52 LOCKWASHER (fixed capstan ONLY) 1
53 WASHER (fixed capstan ONLY) 1
54 CAPSTAN (fixed capstan ONLY) 1
55 KEY (fixed capstan ONLY) 1
For part numbers, refer to PCD-24B Material List,
Publication Number PB-244.
