BRAND-MAN Rustler2 - Step 2: Cart Bottom Panel Assembly

a) Turn Cart Bottom Panel (14) o6er and attach Gas Cylinder Fixture Support (17) with two
screws (A).
b) Insert Cart Cylinder Fixture (17) through rear edge of Cart Bottom Panel (14) and
Gas Cylinder Fixed Support (16).
c) Attach Left Bottom Cabinet Panel (36) to Cart Bottom Panel (14) with two screws (A).
d) Repeat STEP 2 c) for right side as shown in the diagram.
Step 2
36
30
14
16
17
17
