BRAND-MAN Rustler2 - Steps 21-22: Right Door and Grease Pan

20
ASSEMBLY INSTRUCTIONS (CONTINUE)
Step 21
the pre-drilled hole found in Right Cabinet Bottom Panel (30)
b) Next press the spring door pin and slide into place as shown the diagram.
Step 22
a) Attach Grease Cup Support (4) onto the Grease Pan (3) with four screws (B) as shown.
b)
P
34
3
4
M4X12 ...4 PCS
B.
