5601 - 4
BINC Rev: 9/99 Service Documentation
Service Information
BAG Rev: 9/99 5601
Technical Data Principle Rechargeable / cord shaver
Nominal voltage 120 VAC
Nominal frequency 50 - 60 Hz
Housing Plastic material
Cutting system Switchable double cutting system
(21 resp. 33 mm width)
Switch function Central sliding switch with integrated "speed"-shifting
and button for lock function
Separate memory slide for 7 beard-length positions
(1 - 2 - 3 - 6 - 9 - 12 and 16 mm)
Drive 1.2 V DC motor
Revolutions switchable to two positions
Position 1: approx. 4.760 r.p.m. (min.)
approx. 6.120 r.p.m. (max.)
Position 2: approx. 5.600 r.p.m. (min.)
approx. 6.800 r.p.m (max.)
(after a recharging time of least 3 minutes and with
greased cutting system)
Power transmision Via eccenter directly onto the shaving system
Power supply Via a built in, rechargeable NH-battery, resp. a built-in
battery recharger
Charging time EP 100 approx. 1 hour
EP 80 approx. 8 hours
EP 60 approx. 16 hours
Power consumption EP 100 approx. 4 watts
EP 80 approx. 5 watts
EP 60 approx. 1,35 watts
Charging of the shaver Is indicated by a green lamp
Operating capacity after full recharge
approx. 30 cutting minutes
