Braun L955 - Manual Platform Unfolding; Manual Platform Lowering

Page 32
Open
(Down)
Close
(Up/Stop)
Manual Operating Instructions
Refer to photos and illustration of
release valve on previous page.
To Unfold Platform (Out):
Using hand pump handle (Photo B):
a. Place slotted end of pump handle
onto back-up pump release valve
and turn counterclockwise
(open — 1/2 turn only) until the
platform reaches floor level
(fully unfolded). See Photo C.
b. Turn the release valve clockwise
(close) to stop the platform. See
Photo C.
Note: Valve must be tight, but do
not overtighten.
Place slotted end of pump handle
onto back-up pump release valve
DOWN
• To Lower Platform:
• To Unfold Roll Stop:
B
C
Hand
Pump
Handle
and turn counterclockwise (open
— 1/2 turn only) until the platform
reaches ground level and/or roll
stop unfolds.
