7
Assembly Instructions:
IMAGE 2
IMAGE 3
IMAGE 4
IMAGE 1
5
1. Connect the tubes as shown in IMAGE 1.
2. Spread out the net #7 as shown in IMAGE 2.
3.
Drape the net #7 over the soccer goal and secure the net to the goal on all sides
using Strap #10 (30 pieces).
4. Using the 8 “J” pegs #6, hook pegs over frame poles and push
into the ground to secure the goal in the position shown in image 4.
4 pegs are to be used across the back of the goal and 2 are to used
for each side pole (see IMAGE 4).
5. Using Air Pump # 9, pump air into Ball #8.
1
3
1
5
5
2
4
2
6
2
remove space between
# and 9
