31
DECRIPTION
ERROR
CODE
EVERYTHING OK,
GROUND MODE ACTIVE!
STARTUP
ROTATING
DRIVING
LIFTING
LOWERING
STEERING
SELECT DRIVE/LIFT MODE
CLOSE TRIGGER
VEHICLE TILTED
FAULT: BAD P/N 1,1
NOT CALIBRATED 1,1
HEIGHT NOT CALIBRATED 1,1
FUNCTIONS LOCKED - NOT CALIBRATED 1,1
FUNCTIONS LOCKED - TEST MODE SELECTED 2,2
FUNCTIONS LOCKED - POTHOLE 2,2
FUNCTIONS LOCKED - ARMGUARD 2,2
FUNCTIONS LOCKED - OVERLOADED 2,2
FUNCTIONS LOCKED - UNDERLOADED 2,2
FUNCTIONS LOCKED - TOO HIGH 2,2
FUNCTIONS LOCKED - TILTED 2,2
FUNCTIONS LOCKED - EXTERNAL SHUTDOWN 2,2
DRIVE LOCKED - CANNOT STEER 2,2
CHECK GROUND INPUT SWITCHES 2,2
CHECK DRIVE/LIFT SELECT SWITCH 2,2
CHECK JOYSTICK 2,2
RELEASE TRIGGER 2,2
RELEASE GROUND SWITCHES 2,2
RELEASE ROTATE SWITCHES 2,2
RELEASE JOYSTICK SWITCHES 2,2
SHUTDOWN - CHECK EMS SWITCHES 2,1
FAULT: ENERGIZED VALVE - CHECK P9 WIRING 3,2
FAULT: BAD INTERNAL SAFETY OUTPUT 3,4
DRIVE LOCKED - BRAKING 3,4
MOTOR OVERLOAD 3,4
FAULT: CAPBANK VOLTAGE TOO HIGH - CHECK LINE CONT 3,3
FAULT: VALVE FEEDBACK HIGH - CHECK VALVE WIRING 3,2
FUNCTIONS LOCKED - BATTERY 4,4
FAULT: BAD INTERNAL 12V 4,3
FAULT: BAD 5V JOYSTICK SUPPLY - CHECK P15-12 WIRING 4,5
FAULT: BAD INTERNAL 5V 4,2
FAULT: BAD TILT SENSOR 4,2
FAULT: BAD INTERNAL SLAVE 4,2
FUNCTIONS LOCKED - TOO HOT 4,2
FAULT: BATTERY VOLTAGE TOO LOW 4,4
FAULT: BATTERY VOLTAGE TOO HIGH 4,4
FAULT: CHECK ELEVATION SWITCH 6,3
FAULT: CAN BUS 6,6
FAULT: MOTOR A SHORT TO HIGH 7,2
FAULT: MOTOR A SHORT TO LOW 7,3
FAULT: MOTOR B SHORT TO HIGH 7,4
FAULT: MOTOR B SHORT TO LOW 7,6
FAULT: MOTOR CONNECTIONS SHORTED 7,5
FAULT: CAPBANK VOLTAGE TOO LOW - CHECK STUD WIRING 7,7
DRIVE LOCKED - CHECK FIELD CURRENT 7,7
B+ SUPPLY ERROR 9,9
BRAKES MANUALLY RELEASED 8,2
