-5-
Plug Connectors
Used to connect controller to with WH-10A/WH-10D
Communication Cable (bottom of controller).
17
Mounting Posts
Offset mounting posts allow for accurate sensing of air
temperature and humidity by minimizing contact of the
controller with attic framing members.
18
19
Network Channel Selector
Used to assign a unique wireless network address to the fan
controller. Network designed to accommodate up to 10 fan
controllers.
20
Mounting Holes
Design to fit #8 wood screws (included with controller).
Getting Started
The Breeze Mate™ solar ventilation system is designed for
easy installation and configuration. However, if you require
assistance, Attic Breeze is here to help.
Customer Support
Monday - Friday 8:30AM - 5:30PM CST
254-865-9999
support@atticbreeze.net
The Breeze Mate™ CS-10A and CS-11A control
systems are designed for use with Attic Breeze
model solar attic fans featuring a unit mounted
solar panel. If your Attic Breeze fan features a
remote mounted solar panel, the CS-10D or CS-11D
control system is appropriate for your installation.
Contact Attic Breeze customer support for more
information or consult your local Attic Breeze dealer
for additional assistance.
!
