Apply the Sequential Compression Therapy pads to the patient’s calves.
Apply 1 Cold-Dynamic Compression pad to the appropriate body part (Example: knee)
(Refer to the other available pads for the application instructions for each pad.)
Center the pad behind the
patient’s calf.
Wrap one side of the pad, as
shown, around the front of the
patient’s leg.
Secure by wrapping the 3 “fingers” in the
order shown around to the front. Apply pads
to both calves. Adjust so snug. Do not over
tighten.
Center the pad over the patient’s knee with the
connector pointing down.
Wrap straps around the knee to secure the pad.
Attach the container to the pads using the
corresponding colored connectors as shown. The
connectors make a “click” sound when fastened
properly.
Plug the container into a grounded AC outlet.
Apply therapy pads only to body part indicated for the associated pad. failure to follow the
product instructions may lead to improper product performance and the potential for serious
injury.
1 2 3
4 5
6 7
Attach the Container to the pads via the tubing set.
Operating Instructions
Applying Therapy Wraps and Pads
