Bi-directional mode
Page 3
Matchable Motors and Receivers
Installing the Motor
Note: If to change the installation position, open the power terminal box, loosen the screw and
adjust to the desired position then tighten the fixed screw.
Uni-directional mode
DC1600
DD116H
DC1536 or other uni-directional receivers.
DD1600H
DD116H
DM45EAC/S or other bi-directional receivers.
Push up to
open the cover
Fixed
screw
Power wiring
Neutral
DD116H DD116H DD116H
Installation
(1)
Installation
(2)
Installation
(3)
Live
Image Required
Image Required
