Bremshey BE7 - Package Contents (Fig. B & C); Description (Fig. A)

Package contents (fig. B & C)
▪
The package contains the parts as shown in fig. B.
▪ The package contains the fasteners as shown in fig. C. Refer to the section
“Description”.
NOTE
– If a part is missing, contact your dealer.
Description (fig. A)
Your upright bike is a piece of stationary fitness equipment used to simulate cycling
without causing excessive pressure to the joints.
1 Pedal 8 Handlebar
2 Pedal strap 9 Handlebar adjustment knob
3 Main housing 10 Hand pulse sensor
4 Seat 11 Support foot
5 Seat adjustment knob 12 Transport wheel
6 Seat tube 13 Console
7 Seat tube adjustment knob 14 Console adjustment knob
Fasteners (fig. C)
15 Carriage bolt (M8*55) 21 Screw (M4*16)
16 Washer (D8*19) 22 Screw (M5*12)
17 Locknut (M8) 23 Carriage bolt (M8*75)
18 Allen bolt (M8*16) 24 Bushing (D14.8*25)
19 Curved washer (D8*19) 25 Screw (M5*14)
20 Spring washer (D8)
EN
BE7 13
