ATTENTION!
Make sure that the power switch is at the OFF position.
Open the battery compartment door and remove the battery
tray, by turning the two holders to the side. Install the fully
charged batteries into the battery tray according the polar-
ities shown. Re-Insert the battery tray. Pay attention to the
correct orientation (see illustration).
The following batteries with 1.5V output can be used:
1. High-density and high-performance alkaline batteries
(Recommended)
2. Rechargeable alkaline batteries
3. Rechargeable NiMH batteries
3.2 Insert the SD-card
Open the battery compartment door. Insert the microSD
card into the card slot with the unmarked side facing
upwards. Please note that the microSD card can only be
plugged in in one direction. Make sure that the write-pro-
tect switch of the SD-card is in the “write” position; other-
wise the camera cannot be switched on.
3.3 Power on the camera
Before switching on, please pay attention to the following:
1. Avoid temperature and motion disturbances in front of
the camera such as big leaf, curtain, air-conditioner, air
outlet of a chimney or other heat sources to prevent
false triggering.
2. The height from ground for placing the camera should
vary with the object size appropriately. In general, one to
two meters are preferred.
3. Slide the power switch to the ON position to power on
the camera.
After switching on the camera, the indicator LED (red) will
blink for about 10s. The 10s is a buffering time e.g. for
closing and locking the bottom cover, fi xing the camera on
a tree and walk away. After 30 seconds the device starts
the autonomic capturing of pictures. If no SD card is insert-
ed, the device switches off automatically after 30 seconds.
3.4 Setup Menu
1. Press the „MENU“ button to enter the settings menu.
2. Press the arrow keys UP or DOWN to select a menu item.
3. Press „OK“ to edit the menu item.
4. Press the arrow keys UP or DOWN to change the value.
5. Press „OK“ to confi rm.
