2022 Owner’s Manual Eagle 8 BRIG ltd
30
FRESH WATER SYSTEM (SHOWER)
.
You can see the main components of the fresh water system in Fig.9.
The water in the fresh water system is not intended for drinking.
1- water tank 43L (11 gal)
2- tank fixing bracket
3- shower pump
4- water purification filter
5- shower handset with push button
control and shower hose
6- neck for water fill
7- nozzle and hose for ventilation of
the water tank
8- console switch panel
9- fresh water pump control switch
“SHOWER PUMP”.
Fig.9
How to operate with fresh water system:
1.
Open the filler neck (6). The filler neck is labeled "Water". Fill the tank with fresh water (43L (11 gal).
The water
tank does not have a level sensor. The tank is completely full if water flows out of the ventilation nozzle (7) of the
water tank.
Close the filler neck tightly.
